WR300 Pressure Vessel Welding Turning Rolls for the ship boiler , VFD Control Turning Roller
- T/T L/C D/P D/A
- 7 days
You May Like
-
5T Adjustable Welding Turning Rolls For Automatic Welding Machine
-
Automatic Weld Manipulators WM7070 With High Efficiency For Steel Structure
-
Horizontal Self-aligned Vessel Tank Rotator Welding Machine To Weld In Blue
-
Custom Ajustable Convenient Tank Rotator , Self-aligned Welding Turning Rolls
-
1200 Ton Conventional Welding Tank Rotator For Construction Of Wind Tower
-
Fit-up Horizontal Tank Turning Rolls , Self-aligning Pipe Welding Rotators
Product Details
| Brand Name | Yijie | Place of Origin | China | |
| Model Number | WR |
Product Description
Certification:CE
?
The WR300 welding rotator :The workpiece diameter from 1500 to 9000 mm,The Center to Center distance are?4 steps---1700-2500-3300-4100 mm, you may easy change the wheels distance , the very important information is the key between the frame and the bed.
Type | Max Loading Ton | Vessel Diameter Range? mm | Wheel Size mm | Motor Power KW | Linear Speed M/ h |
|
Diameter | Width | |||||
WR5 | 5 | 250---2300 | 250/240 | 100+20*2 | 0.37*2 | 6---60 |
WR10 | 10 | 320---2800 | 300/290 | 120+25*2 | 0.55*2 | |
WR20 | 20 | 450---3500 | 350/340 | 120+30*2 | 1.1*2 | |
WR40 | 40 | 600---4200 | 400/390 | 120+40*2 | 1.5*2 | |
WR60 | 60 | 750---4800 | 450/440 | 120+50*2 | 1.5*2 | |
WR80 | 80 | 850---5000 | 500/490 | 120+60*2 | 2.2*2 | |
WR100 | 100 | 1000---5500 | 500/490 | 120+70*2 | 2.2*2 | |
WR150 | 150 | 1200---6500 | 600 | 280 | 4*2 | |
WR200 | 200 | 1500---8000 | 700 | 300 | 5.5*2 | |
WR500 | 500 | 1800---8000 | 800 | 300 | 7.5*2 | |
WR1000 | 1000 | 2000---10000 | 1000 | 350 | 11*2 | |
Remote control box line length:8m |
