8 Watt 900Lm Bridgelux COB LED 130 Degree 80 CRI With CE Approved
- T/T L/C D/P D/A
- 7 days
You May Like
-
Bridgelux LED Module 60W 5000K Natural White Flood Light LED Module
-
150W Outdoor LED High Bay Light 38 Degree 110 - 130LM/W Cool White
-
IP65 80W Outdoor LED Street Lights , Railway Tunnels Lighting
-
High Light Efficiency Outdoor LED Street Light 135-155lm/w Led Street Light Module 20W - 30W
-
Aluminum Outdoor LED Street Lights Module 200W IP66 With Bridgelux LED
-
10W 45mil Bridgelux LED Module 1100LM 120 For Flood Light
Product Details
| Brand Name | Lepower | Place of Origin | China | |
| Model Number | LY-IHN30801B4545 |
Product Description
Certification:CE|RoHS
High efficiency 900lm 8W cob led module with factory patent
Quick Detail:
8W power consumption COB package, high light efficiency Bridgelux led chip customized 24-27V, 320mA, up to 100lm/W,Ra>80 Size: D13.8mm*L21mm Warm white/Natural white/Cool white optional Match with Lepower exclusive lens, light transmittance rate can be up to 92% CE, RoHS, EN62471 compliance, LM-80 under testing Flexible solutions for various kinds of product. 2 years warranty8 Watt 900Lm Bridgelux COB LED 130 degree 80 CRI With CE Approved
Description:
Exclusive package design, national patent approved. NX3 led series, 4-12W different power customized Super high lumens light source Several led chips available, easy selection with your goal. Different beam angle lens available, easy control your lightApplications:
Spotlight Track light Down light Stage light High bay lightSpecifications:
Dimension
Electrical/Optical Characteristics (At TA=25°C)
|
Parameter |
Symbol |
Conditions |
Min. |
Avg. |
Max. |
Units |
|
Luminous Flux |
Φ |
IF=320mA |
800 |
-- |
900 |
lm |
|
Color Rendering Index |
CRI |
IF=320mA |
70-- |
75 |
Ra |
|
|
Color Temperature/ Color coordinates |
CCT |
IF=320mA |
2800 |
-- |
3000 |
K |
|
Forward Voltage |
VF |
IF=320mA |
24 |
-- |
27 |
V |
|
Luminous efficiency |
Φ |
IF=320mA |
90 |
-- |
100 |
Lm/W |
|
Thermal Resistance Junction To Board? |
RΘJ-B |
IF=320mA |
? ? |
2 |
? ? |
°C/W |
|
Reverse Current |
IR |
VR=17V |
? ? |
? ? |
2 |
μA |
|
Viewing Angle [1] |
2Θ1/2 |
IF=320mA |
? ? |
130 |
? ? |
Deg |
Absolute Maximum Rating(At TA=25°C)
|
Parameter |
Symbol |
Ratings |
Units |
|
Power Dissipation |
PD |
8 |
W |
|
Continuous Forwar |
