Most Compact 32Ah 12V LiFePO4 Battery for Mobile Medication Carts, Powered Carts

Brand Name	TONGYU		Place of Origin	China
Model Number	12V32AH

Delivery Time:10-15days for samples, 20-25days for batch orders
Certification:CE,ROSH,UN38.3

Most Compact 32Ah 12V LiFePO4 Battery for Mobile Medication Carts, Powered Carts

LiFePO4 12V 32Ah

Weight: <6KG

1. Built-in automatic protection for over-charge, over-discharge and over-temperature conditions

2. Intra-module balancing

3. Maintenance-free

4. Thousands of cycles, under normal conditions

5. Can be charged using most standard lead-acid chargers

Most Compact 32Ah 12V LiFePO4 Battery for Mobile Medication Carts, Powered Carts

Description:

We can design any 12V LiFePO4 with the same SLA case size to replace old SLA battery! Tongyu provide the best price with high quality products, can accept small orders.

Maintenance-free

No memory effect

Low self discharge and longer service lifespan

High discharge rate

Wide operation temperature range

Advantage of lifepo4 battery:

long cycle life???????????? low weight ,small size???????? fast charge/discharge with large current high temperature resistant?????????? large capacity no memory effect???????? ?????????????????? enviroment-friendly

Applications:

Golf trolleys, Golf carts, UPS backup Fire alarm and security systems Telecommunication equipment Electric equipment and telemeter equipment Light equipment, dc 12v led lights Wireless lawn movers vacuum cleaner and washing machine Toys and consumer electronics Solar systems 12v Portable power tools measuring and medical equipment Portable video camera portable personal computer Garden lighting Sound systems And etc

Specifications:

Item	TY-1212F
Nominal?Capacity	32Ah
Nominal?Voltage	12.8V
Normal discharge current	20A
Maximum continuous current	40A
Max pulse instant current	100A(1-5s)
Discharge cut-off voltage	10V
Max charge voltage	14.6V
Charge current	≤15A
Battery housing	ABS 12V 24Ah SLA Case
Charge temperature	0℃～45℃?
Discharge temperature	-20℃～60℃?
Humidity	5%≤RH≤85%
Size(L*W*H)	175*165*125mm
Weight	<6kg
Protection function	Overcharge protection, Over discharge protection, Over current protection, Temperature protection, Balanced function

Compared with Seal lead acid battery, lifepo4 battery has many advantages:

1. Green: Non-Toxic, comfort to RoHS.

2. Long cycle life: > 2000 cycles, while Sealed Lead Acid batteries only 750 cycles and NiMh batteries only 500 cycles)

3. Safety

The safest battery in the world till now, which does not burn with 30V charge voltage and it does not explore when you puncture the battery. UL approved.

4. Light weight and smaller dimension

The dimension is smallest and the weight is lightest when compare with other battery. 1/3 weight of SLA, ?65% weight of NIMH.

5. Great capacity and more powerful, rechargeable battery

High discharge current, 1C continuous, 3C pulse for normal cells and 20 C for special design

We can install many single cells in series and in parallel and it can fully discharge

6. Good thermal stability: - 40°C to 70°C

7. Back fast charge, good consistence, no memory effect, can equip battery charger.

Can be recharged anytime, no reduction of the capacity

8. Widely
