CL909 Weighing Sensor / Load Cell 5-250klb for Trucker Scale
Negotiable
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
CL812 Weighing Sensor / Load Cell 10-50t for Trucker Scale/Hopper Scale
-
CL810 Weighing Sensor / Load Cell 500-1000t for Hopper Scale
-
CL201 Weighing Sensor / Load Cell 1-30t for Hydraulic Press / Hopper Weigher
-
CL217 Weighing Sensor / Load Cell 2-20t for Hydraulic Press/Testing Machine
-
CL120A Weighing Sensor / Load Cell 2-10t for Elevator/Crance Scale/Plateform Weighing
-
CL204 Weighing Sensor / Load Cell 10-200kgs for Elevator/Crane Scale/Plateform Weighing
Product Details
| Brand Name | Erdason | Place of Origin | China | |
| Model Number | CL909 |
Product Description
Model number: CL909
Application: Truck scale
Capacity(klb): 5, 10, 20, 30, 50, 60, 75, 100, 200, 250klb
Output sensitivity (mv/v): 3.0±0.3
Nonlinearity (%): 0.02
Repeatability (%): 0.01
Hysteresis (%): 0.02
Creep (30min) (%): 0.02
Temperature sensitivity drift (Effect on zero %/℃): 0.012
Temperature zero drift (Effect on zero %/℃): 0.018
Zero balance (± %/℃): ±1.0
Input resistance Ω: 700+5
Output resistance Ω: 700+5
Insulation resistance mΩ: 5000
Recommended voltage: 12V
Maximum voltage: 18V
Compensated temperature range ℃: -10℃ - 55℃
Operating temperature range ℃: -35℃ - 65℃
Safe overload %: 150%
Ultimate overload %: 200%
Load cell material: Alloy steel
Connecting cable: 6.3mm x 13 m
