Product Details
| Brand Name | Huamu | Place of Origin | China | |
| Model Number | FSP60 |
Product Description
Certification:ISO ,PRODUCE LINCESE
Reliable?Grind?Corn,?Sorghum?22kw?Hammer?Mill?Machine?For?Grind?Crushed?Cake?Dregs?FSP60
Descrition:
The series Hammer Mill is used to grind granular raw materials for feed, such as
corn, sorghum, wheat, bean, crushed cake dregs and other materials.
The features of this series Hammer Mill are as follows:
Steel plate welding structure is adopted : rotor and motor are mounted on the same base. Pin coupling is adopted for direct driving. The rotors are dynamically balanced and can rotate in two directions. There is interlock safety device on the operation door so that the door can not be opened when the rotors are running. The hammers are symmetrically arranged. This machine has features of simple structure, sturdiness and durability, high productivity, convenient operation, safety and reliability.
Applications:
The?series?Hammer?Mill?is?used?to?grind?granular?raw?materials?for?feed,?such?as?
corn,?sorghum,?wheat,?bean,?crushed?cake?dregs?and?other?materials.
Also?suitable?for?grinding?wood?shavings?,short?straw?and?other?small?biomass?raw?material.
Specifications:
|
Model |
Technologic?parameter |
|
|
FSP50 |
FSP60 |
|
|
Rotor?Diameter(mm) |
500 |
600 |
|
Main?Shaft?Speed(rpm) |
3440 |
2800 |
|
Width?of?Grinding?chamber?(mm) |
273 |
400 |
|
Linear?Velocity?of?Hammer?Sheet(m/s) |
90 |
85 |
|
Number?of Hammer |
12 |
24 |
|
Power?(kW) |
18.5 |
22 |
|
SIZE(MM) |
1170*1020*1125 |
1424*1326*1512 |
Competitive Advantage:
This model hammer mill is widely used in small factory ,farm ,or home.because the hammer mill is old style model ,the capacity can get 1-2t/h.the price is very cheap and easy for operation.
