Scenic Ticketing System Automatic Tripod Turnstile Gate with bar code reader

Brand Name	TDZ		Place of Origin	China
Model Number	TDZ-S312

Certification:CE

Scenic Ticketing System Automatic Tripod Turnstile Gate with bar code reader

?
Quick Details

?Bridge type:1200*280*1000mm Rod length:510 - 600mm fully automatic / semi automatic / manual type are optional One way / bidirectional can be set can use with RFID,Mifare,fingerprint,bar code,facial scanner,etc access control products

Product Descriptions:

According to different control modules, this series can be divided into Fully-Automatic Type, Semi-Automatic Type, and Manual Type.Standard tripod turnstile often use semi-automatic mechansim,if you need fully automtic or manual type,it absolutely no problem

Semi-Automatic Type:
?

Model:?TDZ-S312 Auto-drop-arm function:?the middle arm can drop down automatically (default) (or free passing) when the power is off. Emergency-escape function:?the middle arm will drop down automatically by pressing the emergency button which can be remote-controlled whether the power is on or not. The structure has no motor. ?Both directions can be set as controlled mode or free mode. NO mode & NC mode can be switched over by users easily & freely. With interface of relay switch (the dry contact signal or +12V electrical level signal or DC12V pulse signal of pulse width ≥ 100ms, driving current ≥ 10mA), compatible with all kinds of access controllers.

?
?
Customized Features:
?

Alternative Materials, Finishes and Custom Design Access Control System Integration Ticket System Integration Camera System Integration Thermostat System?Integration Remote-Controlled Button Usage Counters Waterproof and Dustproof Design: IP53 for mechanical module, IP65 for electric module SDK and technical support will be provided for?Secondary development?of software
