Automatic Hydraulic Glazed Tile Roll Forming Machine / Roofing Tile Process Line
Negotiable
/ Metric Ton
1 Metric Ton(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Full-Automatic Standing Seam / Floor Deck Cold Roll Forming Machine 0.4mm - 0.8mm
-
Hydraulic Cutting 5.5KW Roof Rolling Forming Machine , Corrugated Sheet Making Machine
-
Aluminum Sheet Glazed Tile Roll Forming Machine , Roofing Panel Roll Former
-
Metal Roof / Color Steel Glazed Tile Roll Forming Machine , Roofing Tile Cold Making Machine
-
Professional Color Steel Glazed Tile Roll Forming Machine with PLC Control
-
Steel Cold Double Layer Roll Forming Machine for Roof Tile , Metal Sheet , Wall Panel
Product Details
| Brand Name | LUOLE | Place of Origin | China | |
Product Description
Automatic Hydraulic Glazed Tile Roll Forming Machine / Roofing Tile Process Line
Quick details:
1. Condition: New, Type: Tile Forming Machine.
2. Tile Type: Steel, Use: Roof.
3. Place of Origin: Wuxi, Brand Name: LUOLE
Description
The roof tiles manufactured by our Glazed Metal Roof Tile Roll Forming Machine Production Line are beautiful and durable. They are widely used in gardens, factories, resorts, hotels, exhibition halls, vacationlands, ancient architectures and modern villas.
Characteristic of Glazed Tile Roll Forming Machine
This Color Steel Roof Glazed Tile Roll Forming Machine can rollform metal roof tiles. After roll formed by this glazed roof tile roll forming machine, the surface of metal roof glazed tile is very smooth and beautiful without any scratch on the surface of tile profile sheets. The Steel Glazed Roof Tile Roll Forming Machine is with fully automatic control system with PLC. Length, quantity of sheets is adjustable. Roll forming process: Decoiler, Roll forming, Pressing & Cut to length. Easy operation: Key in the length and quantity on the control panel. 1 Year warranty, lifelong time service. We also can do a custom roll forming machine, we can design machines according to your specifications and profile drawings, all our machines are customized.Components of Glazed Roof Tile Roll Forming Machine
| Decoiler / Uncoiler | 1 Unit |
| Feeding Guide | 1 Unit |
| Main Glazed Tile Roll Forming Machine | 1 Unit |
| Hydraulic Pressing for Step | 1 Unit |
| Hydraulic Cutting System | 1 Unit |
| Hydraulic Station | 1 Unit |
| PLC Computer Control Box | 1 Unit |
| Support Tables | 2 Units |
Specifications of Glazed Tile Roll Forming Machine
| Machine Name | Glazed Tile Roll Forming Machine | |
| Material | Thickness | 0.3-0.7mm |
| Coil width | Custom-made, 1000mm or 1200mm or 1250mm | |
| Yield Strength | 250-300 Mpa | |
| Material | PPGI, Color Steel, GI. | |
| Decoiler / Uncoiler | Uncoiler Type | Manual or Hydraulic or Auto Type |
| Coil Width | Max. 1250mm | |
| I.D | 508-610mm | |
| O.D | Max. 1500mm | |
| Glazed Tile Roll Forming Machine | Forming Stations | 13-18 Stations ( Depend on Profiles ) |
| Roller material | 45# steel, surface coated with 0.05mm hard chrome | |
| Diameter of shaft | 76mm | |
| Shaft material | High grade 45# steel | |
| Drive type | Chain transmission | |
| Forming speed | 0-15m/min | |
| Main power | 5.5Kw |
Reference Glazed Roof Tile Drawing
Working Flow of Roof Tile Forming Machine
Decoiler ---> Fedding Guide ---> Roll Forming ---> Pressing ---> Cut-to-length ---> Run out table
Application
Our products are widely used in various industrial factory, civilian building, warehouse and easy steel building manufacturing, and have features such as nice appearance and durable.
Advantages
· Excellent quality
· Reasonable price
· One class after sales-service
· 1 Year Warranty from shipment
· More than 15 years manufacturing experience
