Roofing Sheet Metal Corrugated Roll Forming Machine / Circular Arc Glazed Tile Making Machines

Roofing Sheet Metal Corrugated Roll Forming Machine / Circular Arc Glazed Tile Making Machines

Quick details:

1. The color of machine: depend on your required

2. Feeding Material: color steel coils

3. Control system: PLC control

Description

1.Step steel glazed tile roll forming machine have many types for different shape profile roof

tiles. The glazed roof tile is a new building material made from high-quality color coated steel plate with Step steel glazed tile roll forming machine. They are widely used as the roof of garden-like factory, hotel, villa, exhibition center, civil construction and so on. This machine is controlled by the advanced PLC control system and able to running both automatically and manually. When everything is finished and the machine is ready to produce the tile sheet, the operator just input the required lengths and quantities into the computer through the touch screen, the roll forming machine will run fully automatically until the required lengths and quantities are finished.

2.The structure base of step steel glazed tile roll forming machine is H beam base with steel plate welded stand which is very reliable and good performance.

3.All the components of machine are from brand-famous enterprise so that they ensure the machine normal function very effectively.

4. We adopt the automatic length-fixed forming and cutting to guarantee the length to be precise and the finished product clear without deforming.

Specification

● Material thickness: 0.4-0.8mm

● Material width: depend on customer’s requirement

● Decoiler Type: manual or automatical type ( depend on customer’s requirement )

● Weight Capacity Of Decoiler: 5 Ton

● Main Motor Power: 5.5 Kw

● Hydraulic Motor Power: 3 Kw

● Forming Station: 13-20 ( depend on profile drawing )

● Working Speed: 0-6m/min

● Transporting Type: Chain Transmission

● Type of Cutting: Hydraulic cutting

● Electrical Control: PLC Frequency Control System with touch screen

● PLC: PANASONIC

● Encoder: OMRON

● Transducer: PANASONIC

● Machine Weight: about 5 Ton

pictures:

Application

It is used to support the steel coil and uncoil it in a turnable way. Passive uncoil pulled by roll forming system. Put the raw material(steel plate) through the beach to manufacture and process,it can guarantee that the products are neat, parallel and everything is uniformity. Please refer to the equipment regulation to know the function of locate angle iron.

Advantages

1.Excellent quality

2.Reasonable price

3.One class after sales-service

4.1 Year Warranty from shipment

5.More than 15 years manufacturing experience
