Custom-made Combined Prefab Container House, Galvanized Steel Frame with Marine Paint
- T/T L/C D/P D/A
- 7 days
You May Like
-
Portable Prefab Container House Jointed lengthways to Form 40ft Container House
-
OEM Movable Prefab Container House with Bathroom - Galvanized Steel Frame
-
Assembled Standard Accommodation Prefab Container House (Interior)
-
Movable Prefab Container House made from Galvanized Steel Frame for Site Accommodation
-
Standard FlatPacked Prefab Container House for Temporary Site Office
-
Custom made White Modern Modular Prefab Container House for Guarding and Mobile Washroom
Product Details
| Brand Name | Housespace | Place of Origin | China | |
| Model Number | S20-N |
Product Description
Certification:CCS,SGS,ISO9001,ISO9004,
Custom-made Combined Prefab Container House, Galvanized Steel Frame with Marine Paint
Quick Detail:
? ? ? ? ? ? ? ? Size: L6055mm x W2450mm x H2790mm or?customer specific product
? ? ? ? ?Structure: Galvanized Steel Frame with Marine Paint
Wall and Roof: PU, Rock Wool or Neopor EPS Sandwich Panel
? ? ? ? ? Window: Aluminum or PVC Frame with Clear Glass
? ? ? ? ? ? ? ?Door: Steel Cleanroom Door
? ? ? ? ? ? ? ?Floor:?Vinyl Sheet on Plywood or Cement Board
? ? ? ?Fire Proof: B1 Grade
? ? ? ? ? Lifespan: 30-50 Years
Description:
This product is on the basic of 20 feet container.?With?the modern design and advanced technical skills which made itelegant and comfortable.?It ?has a?good insulation which was made by Neopor (It is made in Germany BSF).?The strong firm structure was made by?galvanized?steel frame,?so the life time will be more than 30-50 years.
Application:
Flat-packed container house is one of our popular products.?It is widely used for office, accommodation, hotel, hospital, commercial?kiosk, parlor,?bedroom, study room, locker?room, ablution?room, school,?shower?room, kitchen, dining?room, works camp,?exhibition,?dormitory, villa, carport, house, coffee room, booth, sentry box, guard house, shop, toilet, warehouse, workshop, plant?and so on.?
Specifications:
Dimension(mm)&Weight(kg)
|
Type |
External |
Internal |
Weight (kg) |
|||||
|
Length |
Width |
Height (package) |
Height (assembled) |
Length |
Width |
Height |
||
|
20’ |
6055 |
2435 |
648/864 |
2591/2790 |
5860 |
2240 |
2500 |
from 1850 |
Floor
|
Steel frame |
- made from cold rolled, welded steel profiles, 4 mm thick |
|
- 4 corner casts, welded |
|
|
- 2 fork lift pockets (except 30’) - distance 1200mm (internal clearance of fork lift pockets: 240×80 mm) |
|
|
- steel cross members, thickness=2mm |
|
|
Insulation |
- 100 mm thick Rock Wool |
|
Subfloor |
- 0.5mm thick, galvanized steel sheet |
|
Floor |
- 18mm plywood board |
|
-???????? 1.8mm PVC floor -???????? flammability class B1 - hardly combustible -???????? smoke density class Q1 - low smoke emission -???????? wear resistance factor: T level |
Roof
|
Steel frame |
- made from cold rolled, welded steel profiles, 3mm thick |
|
- 4 corner casts, welded |
|
|
- steel cross members, thickness=2mm |
|
|
Roof cover |
- 0.5mm thick, galvanized steel sheet - 360 degree seaming at joint of roof panels |
|
Insulation |
- 100 mm thick Rock Wool |
|
Ceiling |
- 10 mm chipboard (V 20), laminated on both sides, white - the chipboard complies with the emission value E1 |
|
CEE connector |
- sunken in frame on short end side |
In
