10 Inch All in One POS System / Machine with Receipt Printer / Customer Display

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	ZONERICH		Place of Origin	China
Model Number	ZQ-P1088 mini

Product Description

Delivery Time:7 to 30 days

10 Inch All in One POS System / Machine with Receipt Printer / Customer Display

10\" Aluminum Housing All in One POS System with Receipt Printer and Customer Display

PRODUCT NAME: SMART POS SERIES

MODEL#: ZQ-P1088 mini

HIGHLIGHTS

Main housing made by Aluminum Built-in 80mm Seiko mechanism thermal printer Various options of peripherals Capacitive multi-points touch panel Fan less design Operator display angles adjustable

OPTIONAL

MSR/ Dallas key/RFID

SPECIFICATION

CPU	Intel Atom D2550@1.86GHZ
Memory	DDRIII 2GB
Storage	Mini SSD 32GB or 2.5’’ SATA 320GB
Graphics	Intel Graphics Media Accelerator 3650
Audio	ALC662 Intel Nm10
Operator Display	9.7’’, LED Back light, 1024×768 LVDS Projected Capacitive touch, USB
Customer Display (Three choose one)	LED: 10 Digit, DC5V, RS232, 2400BPS, Characters: 0…9 VFD: 220 Digit, DC5V, RS232, 9600BPS, ASCII code, Page 0 (PC437:USA,StandardEurope); Page 1 (Katakana); Page 2 (PC850:Multilingual); Page 3 (PC860:Portuguese); Page 4 (PC863:Canadian-French); Page 5 (PC865:Nordic); Page 6 (Slavonic); Page 7 (Russia); Page 12 (Greek); Page 16 (WPC1252); Page 19 (Pc858 Euro); PAGE36(PC862,Hebrew) LCD: 220 Digit,DC5V, RS232, 9600BPS; ASCII code
Internet	Ethernet 10/100/1000M
Thermal Printer Model	80mm Thermal Printer, Automatic cutter, Max 170 mm/sec, Diameter Max.￠80 mm, GB2312, PC437, Katakana, PC850, PC860, PC863, PC865, WPC1253, Iran, WPC1256, PC737, WPC1250, WPC1252, PC866, PC852, PC858, WPC1257, WPC775, WPC1251, User define
Printer Port	USB and RS232
Card Reader (optional)	USB or PS/2, DC5V±5%,65mA(max)
External Port	1 RS232 serial interfaces, 1 VGA interface, 1 RJ45 Ethernet port, 4 USB interfaces, 1 DC24V input interface, 1 Cash Drawer Interface
Power Supply	DC24V,5A
Environment	Operating temperature and humidity: -10°C ~ 40°C, 20 ~ 80% RH Storage temperature and humidity: -20°C ~ 50°C, 20 ~ 90% RH
Dimension	250(L)X205(W)X 323(H)mm

DOWNLOAD

Catalogue Manual Driver Service manual
