Integrated Tab Down 10/100 Base-Tx Magnetic RJ45 Network Connectors / RJ45 Network Port W/LED
- T/T L/C D/P D/A
- 7 days
You May Like
-
PBT Black Magnetic RJ45 Jack, 10/100base Tab Down Shield RJ45 Transformer w/o led
-
90 Degree Tab- Down Transformer RJ45 for 10/100base-T/TX Applications, Magnetic RJ45, RJ45 Shielded
-
Single port(1X1) Tab Down 10/100M RJ45 Connector with Transformer right angle, RJ45 Ethernet Jack, M
-
OEM Integrated 10/100M Tab Down RJ45 Network Connector with Transformer for 10/100BASE-T/TX Applicat
-
Single port (1X1) Tab Down 10/100base-TX rj45 modular plug with led , Magnetic RJ45
-
Single port (1X1) 100BASE-Tx rj45 Moudlar jack with led Magnetic RJ45, integrated magnetics rj45
Product Details
| Brand Name | OEBN | Place of Origin | China | |
| Model Number | OEBN |
Product Description
Certification:SGS, UL,CE, ISO9001:2008，Reach
Integrated Tab Down 10/100 Base-Tx Magnetic RJ45 Network Connectors / RJ45 Network Port W/LED
P/N:KRJ-109NL
Descriptions:
10/100Base-Tx RJ45 single port 1X1 Vertical with LEDS with side entry Single port 1X1 Tab-Down RJ45 with internal magnetics ???????????? Internal magnetics are 100% electrically tested for HI-POT and functionality Suitable for CAT5&6 fast Ethernet Cable or better UTP 350uHminimum OCL with 8mA bias current High performance for maximum EMI suppression Minimum 1500Vrms isolation per IEEE 802.3 requirement ?ROHS-6 peak wave solder temperature rating 260℃ Operating temperarure range :0℃ to +70℃ Storage temperature range :-40℃ to +85℃ Number of positions:8 Number of contacts loaded:8 Shieded:YES Rohs compliant Length:21.3mm LEDS:YES EMI fingers:YES LEFT LED:Green,RIGHT LED:Yellow Usage:KRJ-109NLMechanical Dimensions:(Unit:mm)
. XX Tolerance:0.25
.XXX Tolerance:0.13
Specifications:
.Insertion?Loss?:1-100MHZ?-1.0dBmax
.Rturn?Loss?:??1-30MHZ?-16.0dBmin
???????????????30-60MHZ?-14.0dBmin
???????????????60-80MHZ?-10.0dBmin
.Cross?Talk?:1-30MHZ?-40.0dBmin
??????????????30-60MHZ?-35.0dBmin
??????????????60-80MHZ?-30.0dBmin
.CMR:1-100MHZ?-35.0dBmin
.Hi-Pot:1500V?AC?6S?1mA
.Turn?Ratio?:1CT:1CT±3％
.OCL:350uH＠100KHZ?100Mv?8mA?DC
.Contacts:0.35mm?thick?phos?bronze?plated?with?6u’gold?in?contact?are?
.Housing?Material:PBT?Black
.Operating?temperature?rang?:0℃?to?+70℃
Schematic:
Material specifications:
Plastic core:Glass fiber filler PBT Black(UL94V-0) Contact:gold pin0.35mm thick phos bronze plated nickel then with 6u’gold PCB Terminal:Phosphor bronze ,Tail-Tin over Nickl Housing:Phenolic, PBT Black (UL94V-0) Metal shell:Copper Alloy ,Tin and Nickel platedApplications:
? Integrated RJ45 connector main used to :
? 10/100M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,optical transceiver,IP phone,
internet set-top box,internet camera,net bridge,computer,telecommunication,MODEM,HomePNA,DSL／ADSL and so on.
Competitive?Advantage:
Keyouda?has?various?types?of?appearance?and?many?kinds?of?internal?schematic?products,high?quality,?customer?firstly?,
100%?test,?0?defect,?short?lead?time?are?our?best?advantages
