Tear Resistance Strainer Brass Wire Mesh Golden 20-200 Mesh

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	JHZD		Place of Origin	China
Model Number	JHZD-PHOSPHOR.B

Product Description

Delivery Time:20days
Certification:ISO

Phosphor Bronze Woven wire mesh-Plain Weave twill weave- filter industry

Quick Detail:

Name	Nickname
Phosphor Bronze Wire mesh	Phosphor Bronze wire cloth
Material	Phosphor Bronze wire

Description:

Wire Material:
Phosphor bronze wire is an alloy wire of copper, tin and phosphor, which offers good corrosion resistance,wear resistance and tear resistance and is frequently used in the making for fine mesh cloth. A kind of copper alloy, with 4% to 9% tin, approximately 0.25% phosphorous, the balance is copper
?

Applications:

Phosphor bronze wire is corrosion resistant, wear resistant and tear resistant. Woven wire mesh and wire cloth made of phosphor bronze wire are mainly used as fine wire cloth in a number of industries.?
Phosphor bronze wire mesh is frequently used in sieving diversified pellet, powder, porcelain clay and glass, chinaware printing, filtering liquid and gas.We are capable of supplying brass wire mesh from 1-200mesh, and phosphor bronze wire mesh from 1-500mesh. Width from 0.6m to 1.3m, length from 15m to 100m. The following specifications are listed for your reference.

Specifications:

Mesh/Inch	S.W.G	aperture (mm)	wire diameter (mm)	NW(kg/ m2)
80	42	0.271	0.101	0.50
100	43	0.168	0.091	0.45
120	45	0.140	0.071	0.40
150	46	0.108	0.061	0.33
160	46	0.087	0.061	0.35
180	47	0.09	0.051	0.28
200	47	0.077	0.051	0.29
220	48	0.065	0.051	0.32
250	48	0.061	0.041	0.24
280	48	0.056	0.035	0.18
300	49	0.054	0.031	0.16
320	49	0.046	0.031	0.17
330	49	0.042	0.031	0.175
350	49	0.039	0.031	0.18
360	49	0.0385	0.025	0.15
400	50	0.0385	0.025	0.15

Special specifications can be produced by the customer\'s requirements.
