Automatic Feed Discharge Shot Peening Equipment Sandblasting Machinery For Surface Cleaning

Automatic Feed Discharge Shot Blasting Machine For Surface Cleaning with CE

Works

The workpiece into the rubber track roller, the operator presses the \"Run\" button, pneumatic blasting chamber door closed, shot blasting began, crawler moves forward, constantly roll artifacts, powerful and efficient high-speed blasting will Shot the projectile to the workpiece surface is rolling, the workpiece can be cleaned completely uniform. Shot inflows slipped through the hole on the track screw conveyor, steel shot and then transported to the bucket elevator, the bucket elevator upgrade to the splitter, after being separated stored for later use. After blasting, shot blasting chamber door open automatically, track reversal, the workpiece unloading.

Product Features

A reference to Germany at the end of the nineties blasting machine manufactured domestically.
2, the use of powerful and efficient direct-blasting, high transfer efficiency, blasting volume.
3, efficient air separation unit, pill sand separation rate is greater than 99%.
4, projectile uniform coverage without blasting corner.
5, wear parts and long service life, replace rapidly.
6, the device low noise operation.

Scope

Cleanup die casting, precision castings, precision forgings, etc., light decoration. Removing heat, castings, forgings surface oxide. Strengthening of the spring. Fasteners rust and pre-treatment.

Description:

Shot peening is a specialized blasting process that bombards a metallic work piece with a round abrasive, typically steel shot, glass beads, or ceramic shot, thereby compressing the surface. This compression can greatly improve the strength and fatigue life of the part. An analogy would be the blacksmith that hammers a sword to increase its strength.

Completive advantage:

There are cyclone separation system and dust removal system , separator will separate the
abrasive from bust .and dust removal system can deal with and collect the emit useless dust ,dust remove effect of good
.reduce the cost of abrasive and improve efficiency .and there is no environmental pollution .

Sandblasting results:

Abrasives for sandblasting machine( steel shot,Stainless Steel Balls,Glass Beads,White Corundum)
