Eyeliner Lipstick Mascara Filling Machine
Negotiable
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | Broadfair | Place of Origin | China | |
| Model Number | HX-LE02-T+HX-DL01 |
Product Description
Eyeliner Lipstick Mascara Filling Machine
Detailed Product Description:
Cylinders: Festo & SMC
Pneumatic Components: SMC
PLC: Mitsubishi
Electrical Components: Schneider
HMI: Weinview
Servo Motor: Delta
Tanks: SUS304 steel
Working Table: Stainless Steel Protective Cover
Quick Detail:
1. Capacity: 20-50 pcs / Minute.
2. With Piston Filling system.
3. Double-shell tank with pressure and heating function.
4. For both cool and hot filling.
5. With PID temperature control, tolerance within 0.5oC.
6. Filling tolerance within 0.05g.
Description:
This machine can be used for cool or hot filling of fixed quantity and different viscosity liquid powders to containers of different sizes.
This filling machine is equipped with a 2 meter long conveyor and finished products collection table, turn table is also applicable when needed. The conveyor is removable, and the machine can be equipped with screw apparatus for making spiral products. With simple structure and high precision, the piston filling system is easy for installation, regulating and cleaning. It’s driven by servo-motor and electric sliding table that features in high stability and long service life. Fill-up is decided by the piston stroke, there are 4 fill-up options: 25ml,50ml,75ml,100ml. Fill-up tolerance is 0.05g. The 22-liter pressuring and heating double-shell tank is with PID temperature control with a tolerance of 0.5oC and stirring speed regulator. The switching valve is made of special material and driven by rotating cylinder, with precise match, smooth surface, low expansion coefficient, it works smoothly and remains a perfect sealing-up when heated. This solved the problem of stainless steel valve which easily gets stuck due to its high expansivity when heated.Applications:
Hot filling for: Eye Shadow, Lip Gloss, Lipstick, Lip oil and so on.
Cool filling for: Cream, Lotion, Mascara, Liquid Eyeliner and so on.
Specifications:
| NO. | Description | Specs. |
| 1 | Design capacity | 20-50pcs/min. |
| 2 | Power Source | ΦA(chǔ)C220 |
| 3 | Air Pressure | 6-8kg/cm2 |
| 4 | Unit Weight | 250kg |
| 5 | Power Consumption | 2 kw |
| 6 | Machine Dimensions (L*W*H) | 2,500mm * 1,100mm * 1,900mm |
