Product Details
| Brand Name | Broadfair | Place of Origin | China | |
| Model Number | HX-PW02 |
Product Description
Multi color Mitsubishi PLC Vacuum Liquid Powder Filling Machine With Double switch
Detailed Product Description:
Cylinders: Festo & SMC
Pneumatic Components: AirTac
PLC: Mitsubishi
Electrical Components: Schneider
HMI: Weinview
Tanks: SUS304 steel
Working Table: Stainless Steel Protective Cover
Quick Detail:
1. Capacity: 4-6 Molds / Minute, 2 pcs /mold.
2. Maximum feeding area; 90mm*140mm.
3. Filling with Piston Pushers.
4. 6-8 colors filling available.
5. Filling tolerance within 0.05g.
6. Easy and convenient color change and cleaning.
Description:
The main working process of the machine includes liquid powder feeding and pressing. Firstly, the powder is mixed with solvent and stirred evenly in the cone-shaped tanks and fed to each tray cell respectively by piston-pusher, then pressed to finished product. The machine is safe and easy to handle and only one operator is needed.
The maximum feeding area is up to 90mm*140mm.(traditionally it’s 70mm*70mm). Automatic suction Jig design reduces the liquid powder feeding deviation and defective rate. The tanks are integrated with pushers, which shortens the movement to enhance the feeding speed and is applicable for high viscosity liquid powders. This patented design solved the inner leaking problem and only low viscosity liquid powder is applicable for the traditional powder feeding mechanism. Cone-shaped Tanks with 3 direct links solved the problems of the flat-bottomed ones for the feeding failure caused by insufficient remaining liquid powder, low feeding speed and slow powder replacement. With optional numbers, the rotating straight line feeding piston cylinders are applied for easy operating and regulating, leak-proof,, less feeding pressure loss to stable the products quality. Vacuum pump is supplemented to assist the powder feeding, which helps to enhance the products quality and saves energy with lower noise. Double switch design of the feeding and mould avoids powder suck-back and vacuum in the feeding pipes.Applications:
This Multi-color Liquid Powder filling machine is widely used in the mass production of Eye Shadow, Blush and so on.
Specifications:
| NO. | Description | Specs. |
| 1 | Design capacity | 4-6 molds/min. 2pcs/mold. |
| 2 | Power Source | ΦA(chǔ)C220 |
| 3 | Air Pressure | 6-8kg/cm2 |
| 4 | Unit Weight | 380kg |
| 5 | Power Consumption | 4 kw |
| 6 | Machine Dimensions (L*W*H) | 1650mm * 1250mm * 1810mm |
