Four-Roller Compact Spinning System With General Air Duct And Filter Net

Four-Roller Compact Spinning System With General Air Duct And Filter Net

Description:

Hairiness: Hairiness in 3mm length or above could be reduced at least 60%

Strength: The yarn strength is 5% to 15% higher than common ring spinning

Evenness/CV%: Improved CV value

Loom Efficiency: Up to 15% enhanced machine efficiency

Increase productivity, especially for high density fabrics produced in air jet looms.

Q.CHEN compact spinning is four-roller device designed for modification on existing traditional ring frames. Enjoying perfect structure, good workshop, its performance is well accepted ever since its launching market.

Four-roller system,apron lattics are of positive drive.
·Negative pressure system adopt main blower with general air duct and filter net to avoild

dirtying workshop.
·Modular design,6 spindles or 4 spindles in one unit.
·Well-designed negative pressure distribution ensures consistency of airflow at each suction

nozzle.
·The suction nozzle of suction pipe is of optimization design for integrating the strand of

fiber easily.
·Inverter is available for controlling the negative pressure of compat spinning for different

yarn count.
·Smoothly moving of the yarn is guaranteed by tension device of the apron lattice
·Installation of flute pipe is reasonable,parts concerned can be cleaned dynamically

Applications:

Ring frame textile Machinery

Specifications:

·Increase the fibers availability factor.
·When producing yarn of same tenacity,compact spinning has higher production

?efficiency than traditional ring spinning.

Twist in yarn can be reduced by 5-10% while maintaining same yarn strength.

·30% reduction in yarn breakage in warping process.

·Better abrasion resistance of yarn leading to fewer breaks in weaving.

·Singeing can be omitted in case of compact siro-spinning.

·Reduction of pilling and better dye-uptake in fabric.

Competitive Advantage:

Very goog quality

Most model ring spinning frames can be converted.

It has been exported to overseas market. After long period market application and technical improvement, It is a mature compact device.

Tell us your need, we will give a satisfied solution
