High Speed 11kva 8.8kw Brushless Exciter Synchronous Generator 8800 Watt Alternator
- 0 Kilogram / Kilograms per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
12.8kw 16kva Single Fulcrum Brushless Motor Alternator 110 - 240V / 230 - 460V
-
100 kva 3 Phase Brushless Alternator For Diesel Generator Set With AVR SX460 MX321
-
Double Bearing Brushless Alternator 120 kw 140kw 150kw Class H Insulation Generator
-
16kva 13.5kva IP23 Brushless Alternator Generator With Exciter , AVR SX440T / AS440
-
8 kva To 300 kva Stamford Three Phase Brushless Alternator Motor Generator
-
PF 0.8 Diesel AC Generator 1500 , 1800 rpm Self-exciter Synchronous IP22 Standard
Product Details
| Brand Name | Farrand | Place of Origin | China | |
| Model Number | FLD 164 SERIES |
Product Description
Certification:CE ISO
High Speed 11kva 8.8kw Brushless Exciter Synchronous Generator 8800 Watt Alternator
Quick Detail:
1. Brushless alternator with exciter
2. SHUNT excitation with AVR
3. Winding 12 wires 2/3 pitch
4. IP23 enclosed
5. Prime mover:diesel or engine
6. Fulcrum:fulcrum optional single or double,single fulcrum optional
7. specification of the transition then sets and comectivity disc.
Description:
A range of quality dual voltage three phase brushless alternators available in a variety of sizes and prices, so you can find the configuration that works best for your application.
Brushless Alternator provide self excitation and a stable output with the use of an automatic voltage regulator.
Brushless Alternator may be coupled to a prime mover (driving engine) either by a direct shaft to shaft coupling or by conventional belt and pulleys. The AC frequency of the output power is determined solely by the speed of rotation of the prime mover, the alternators must spin at 1500 RPM to generate 50Hz /60HZ power. They can be driven either clockwise or anti clockwise to suit your application.
Please note that the colour supplied may vary from that shown in the picture.BUT WE CAN MEET YOUR REQUIRMENTS.
Specifications:
| Jiangsu Farrand Alternator Technology Co.,Ltd | ||||
| 4-Pole Farrand Brushless Alternator Specifications 3 phase H Class Temperture-rise(125°C) | ||||
| Rating Power Factor | 0.8/1 | |||
| Altitude | 1000m | |||
| Insulation Class | H | Excitation System | Shunt | |
| Lead Number | 12 | A.V.R Model | SX460/MX321/MX341/SX440/SX440T/AS440 | |
| Winding Pitch | 2 / 3 | Voltage Regulation | ±1% | |
| Ingress Protection | IP 22 / 23 | Transient Voltage Recovery Time(s) | ≤1.0 | |
| Waveform:NEMA-MG1 | ≤50 | Waveform:IEC-THF | ≤2% | |
| Ambient Temperature | 40° C | 40° C | 40° C | 40° C |
| Temperature Rise | 125° C | 150° C | 125° C | 150° C |
| Phase / Insulation | 3 Phase / H Class | 3 Phase / H Class | ||
| Frequency | 50Hz(1500rpm) | 60Hz(1800rpm) | ||
| Voltage ( V ) | 170-454 | 110-240/230-460 | ||
| Type | Capacity | Capacity | ||
| Rated capacity/kva | Rated power/kw | Rated capacity/kva | Rated power/kw | |
| FLD164A | 8.1 | 6.5 | 10.2 | 8.2 |
| FLD164B | 11 | 8.8 | 13.8 | 11 |
| FLD164C | 13.5 | 10.8 | 16.9 | 13.5 |
| FLD164D | 16 | 12.8 | 20.2 | 16 |
Competitive Advantage:
Brushless Alternator?100% copper wire Brushless Alternator?Strict quality control system Brushless Alternator?Competitive price Brushless Alternator?Good ServiceContact Us
