PLC Single Screw Extruder Ppr Plastic Pipe Production Line 120kg/h

Brand Name	POLYTECH		Place of Origin	China

Delivery Time:30 days after perpayment
Certification:ISO9001-2000；CE

PLC single screw extruder ppr plastic pipe production line 120kg/h

Quick Detail:

The PPR pipe making machine is mechanotronics, with the advantages of:

1. Modern technology
2. Optimized design
3. High output
4. Stable plastification

Description:

The PPR pipe making machine composed of single screw extruder, vacuum calibrating bath, spraying cooling bath, haul-off unit, cutter and tilting stacker; Coordinated with different specification of molds, to produce pressure water-supply, draining, gas pipe; High heat resistance, environmental stress and crack resistance Specially designed screw, decelerator with high torque and high power DC motor ensure good mixture of material and high output; Adding two more extruders, the line can produce glass-fiber reinforced pipe.

Competitive Advantage:

This PPR pipe cutting machine equipped with different extrusion dies, screws and downstream line, the extrusion line can also produce PE,ABS,PE-RT and PEX pipes.The highest rank machine equipped with PLC system and touching monitor with big screen, is highly automated with better reliability and stability.

Specifications:

Model	SJGZ-63	SJGZ-160
Extruder	SJ65	SJ90
Pipe range(mm)	16-63	75-160
Screw diameter(mm)	65	90
L/D ratio	33:1	33:1
Max output(kg/h)	~120	~300
Linear speed(Max,m/min)	12	4
Main motor power(kw)	37	110

Applications:

This PPR pipe cutting machine can produce PP-R pipe,PE-RT pipe,PEX pipe. PP-R pipe is non-toxic,healthy,heat-resistant and have good performance of warm keeping, it is convenient for welding and can also be recycled. PEX pipe has good character of high and low temperature resistant. Different from? PEX, PE-RT don\'t need to crosslink but can be recycled and convenient for processing with the character of heat-resistant and better stability.

?PPR pipe making machine ,pipe cutting machine, single screw extruder
