Home > Products > Thermostatic?Steam?Trap > Bimetallic Thermostatic Radiator Steam Trap 0.01 - 1.6 MPa
Bimetallic Thermostatic Radiator Steam Trap 0.01 - 1.6 MPa
USD $30 - $30
1 (Min.Order)
- 0 per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | HONGFENG920 | Place of Origin | China | |
| Model Number | TB11 |
Product Description
Certification:ISO9001 & API
Bimetallic Thermostatic Steam Trap 0.01 - 1.6 MPa? ?TB11
Quick Detail:
Model: TB11
Feature: bimetallic type?????????????????? ??? ?
Structure:Thermostatic Steam Trap
Pressure:0.01 - 1.6 MPa?????? ?
End Connection: Screw, Flange, Socket Welded?????????????
Application:? steam main pipe, steam tracer? etc...
Thermostatic Steam Trap
Tight Shut-off with SCCV System
Adjustable Discharging Temp.
Water Seal No Steam Loss
Installed In Any Direction
Bimetallic Steam Trap / Thermostatic Steam Trap
Model:
TB11
Features:
1. Tight shut-off and long service life by using SCCV system. 2. Efficient in energy saving---adjustable discharging temperature and effectively using the sensible heat of hot condensate. 3. Discharging temperature can be adjusted when the pipe net is in operation. Can be installed in any direction. 4. Hot condensate exists just before the trap, forming a tight water seal, which ensures no steam loss. 5. Withstands water hammer with outstanding performance of air venting. 6. Operating without noise, benefiting for environmental protection. 7. Full open at the beginning of steam supplying, discharging cold condensate and air rapidly, which ensures quick start-up. 8. Stainless steel internals are resistant to corrosion and cavitation. Small in size and light in weight, easy maintenance.Application:
This steam trap is suitable for steam main pipe, steam tracer, radiator, low temperature heating trough, jacketed kettle and heating system etc...
Note:
This steam trap\'s Insulation is not recommended for pipe section 1 meter before the trap and the trap itself.
