Cast Steel Inverted Bucket Steam Traps Low Pressure 0.01 - 1.6 Mpa
- 0 per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Medium Pressure Inverted Bucket Stainless Steel 304 Steam Trap PN50
-
Thermostatic Steam Trap SAV1 diaphragm capsule
-
A182F11 Thermostatic High Pressure Steam Trap PN150 PN250 PN420
-
Bimetallic Thermostatic Radiator Steam Trap 0.01 - 1.6 MPa
-
Stainless Steel 420 Impulse Steam Trap
-
1 / 4 \" Impulse Low Pressure Steam Trap 0.03 - 1.0 MPa For Steam Iron
Product Details
| Brand Name | HONGFENG920 | Place of Origin | China | |
| Model Number | ES8B |
Product Description
Cast Steel Inverted Bucket Steam Traps Low Pressure ES8B? ESH10? ES12N
Quick Details:Model: ES8B ?ESH10 ?ES12N
Perfect New SCCV system
Stainless Steel Internals
High Back Pressure & Effective Separation
Air Vent On The Bucket Top
Design Pressure: PN25, PN40
The inverted bucket is the most reliable steam trap operating principle known. The heart of its simple design is a unique leverage system that multiplies the force provided by the bucket to open the valve against pressure.
Since the bucket is open at the bottom, it resists damage from water hammer, and wear points are heavily reinforced for long life. The inverted bucket has only two moving parts-the valve lever assembly and the bucket. That means no fixed points, no complicated linkage. Nothing to stick, bind or clog.
ES8B:
1. Perfect SCCV system can compensate the error produced by the Lever structure, and avoid hard collision, which ensures the tight Shut-off and long service life. 2. Easy access to stainless steel internals simplifies maintenance. 3. Back pressure rate up to 90%. 4. Effective separation of condensate from steam(the steam flows in From bottom of the trap through a U type channel), and no steam Leak. 5. Open float withstands water hammer. Air vent on the bucket top Can effectively prevent steam locking and air Iocking. (Non- Condensable air at high temperature can be discharged as well. )
Application:
Suitable for steam main pipe, steam tracer, steam Separation tank, exchanger, vulcanizer, hot air dryer, cylinder Dryer, distiller, equipment for concentration and sterilizer in Hospital, etc...
