Flange Inverted Bucket Steam Water Trap Casting Steel WCB
Negotiable
1 (Min.Order)
- 0 per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Cast Steel Inverted Bucket Steam Traps Low Pressure 0.01 - 1.6 Mpa
-
Medium Pressure Inverted Bucket Stainless Steel 304 Steam Trap PN50
-
Thermostatic Steam Trap SAV1 diaphragm capsule
-
A182F11 Thermostatic High Pressure Steam Trap PN150 PN250 PN420
-
Bimetallic Thermostatic Radiator Steam Trap 0.01 - 1.6 MPa
-
Stainless Steel 420 Impulse Steam Trap
Product Details
| Brand Name | HONGFENG920 | Place of Origin | China | |
| Model Number | ERH105, ERH110, ERH116 |
Product Description
Flange Inverted Bucket Steam Trap?ERH105? ERH110? ERH116
Quick Details:
Model: ERH105, ERH110,ERH116
Connection:Flange & Screw & Socket Welded
Pressure: 0.05 - 2.5 Mpa
Material: Casting Steel WCB
Temperature: 425 ℃
Working Media: Steam, Condensate Water
?
Specifications:
Inverted Bucket Steam Trap
Double Ported Differential Pressure Mechanism
Small Size Large Capacity
Easy Maintenance
Air Vent On The Bucket
Design Pressure: PN16, 25, 40
Pressure: 0.05 - 2.5 Mpa
Material: Casting Steel WCB
Temperature: 425 ℃
Working Media: Steam, Condensate Water
End Connection: Flange, Screw & Socket Welded
Mechanical Steam Trap / Inverted bucket Steam Trap
ERH105, ERH110, ERH116:
1: With main valve and sub-valve double ported differntial pressure mechanism and SCCV system, the trap is samll in size and large in capacity. 2: Easy access to stainless steel internals simplifies maitenance. 3: Back pressure rate up to 90%. 4: Effective separation of condensate from steam ( the steam flows in from bottom of the trap through a U type channel), and no steam leak. 5: Open float withstands water hamner. Air vent on the bucket top can effectively prevent steam locking and air locking ( Non-condensate air at high temperature can be discharged as well.
Application:
Suitable for steam using equipment in the industries of petroleum, chemisry, metallurgy, electric power, food, dyeing, textile, and pharmacy, etc. And large discharge capacity tracer.
