Home > Products > SFP + Optical Transceiver > SFP+ Optical Transceiver 10GBASE-LR 1310nm 10km
SFP+ Optical Transceiver 10GBASE-LR 1310nm 10km
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | GB-Link/OEM | Place of Origin | China | |
| Model Number | GB-SFP+-LR |
Product Description
Certification:UL, CE,ROHS, FCC, TUV
10Gb/s 1310nm SFP+ 10km Transceiver
Quick Detail:
|
Product part Number |
Data Rate (Gbps) |
Media |
Wavelength (nm) |
Transmission Distance(km) |
Temperature Range(Tcase)(℃) |
|
|
GB-SFP+-LR |
10G |
Single mode fiber |
1310 |
10 |
0~70 |
commercial |
Description:
GB-LINK SFP+LR 1310nm Transceiver is a “Limiting module”, designed for 10GBASE-LR, and 2G/4G/ 8G/10G Fiber- Channel applications.
The transceiver consists of two sections: The transmitter section incorporates a DFB laser. And the receiver section consists of a PIN photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.?
Applications:?
10GBASE-LR at 10.3125Gbps Other optical linksSpecifications
PRODUCT FEATURES
Up to 11.1Gbps Data Links Up to 10km transmission on SMF DFB Laser and PIN receiver Metal enclosure, for lower EMI 2-wire interface with integrated Digital Diagnostic monitoring Hot-pluggable SFP+ footprint Specifications compliant with SFF 8472 Compliant with SFP+ MSA with LC connector Single 3.3V power supply Case operating temperature range:0°C to 70°C? Power dissipation < 1.5 W
Competitive advantage:
?
