Industrial Cryogenic Oxygen Plant , Low Pressure Air Separation Unit,purity :99.7%
- T/T L/C D/P D/A
- 7 days
You May Like
-
100m3/hour ,180m3/h,250 m3/h Small Size Cryogenic Oxygen Plant For Oxygen Production
-
Industrial Liquid Oxygen Plant , Nitrogen / Oxygen Generating Equipment Medical and industrial use
-
Cryogenic Liquid Oxygen Plant , 50 - 2000 m3/hour Air Separation Unit,Liquid Oxygen Tank
-
50 - 1000 m3/hour Industrial Liquid Oxygen Plant , Oxygen Gas Production
-
15 - 25 Mpa Medical Liquid Oxygen Plant , 99.7% Purity O2 Plant
-
Small and Medium Size Liquid Oxygen Plant , Liquid Oxygen Tank
Product Details
| Brand Name | UIG | Place of Origin | China | |
| Model Number | KDO, KDON ,KZO,KZON |
Product Description
Certification:ISO 9001:2000
Industrial Cryogenic Oxygen Plant , Low Pressure Air Separation Unit
Quick Details:
Condition: new
Place of origin: China(mainland)
Brand name: UIG
Model number: KDO, KDON ,KZO,KZON SERIES
Production capacity:50-2000 m3/hour
Power :60-1000 KW
Voltage:380v,400V,440V
Certification: ISO 9001:2000
Warranty:1 year
Life:20 years with proper maintenance
After-sales service provided: Engineers available to service plants overseas
Usage: Industrial and medical (oxygen, liquid oxygen, nitrogen, liquid nitrogen)
UIG Air separation plants are designed for a vast range of capacities and products summarized below: FOR OXYGEN 99.7 % AND NITROGEN 99.999%
Specifications:
Two compression methods:
1)Internal compression air separation plants:
Air-Compressed-Pre-cooling-Purifier-Rectification-heart exchanger (low pressure liquid)-Liquid oxygen pump(pressurized liquid oxygen)-oxygen vaporizer - oxygen cylinders
2)External compression air separation plants:
Air-Compressed-Precooling-Purifier-Rectification-heart exchanger (low pressure gas)-oxygen storage-oxygen compressor(pressurized oxygen)-oxygen cylinders
?The main technical specifications of internal compression
|
Model contents |
KZON- 50/50 |
KZON- 80/80 |
KZON- 100/100 |
KDON- 180-20 |
KDON- 300-50 |
KDON- 350-80 |
KDON- 500-150 |
KDON- 800-200 |
KDON- 1000-300 |
|
|
Gox flow |
Nm3/h |
50 |
80 |
100 |
180 |
300 |
350 |
500 |
800 |
100 |
|
Gox purity |
％(O2) |
≥99.6 |
≥99.6 |
≥99.6 |
≥99.6 |
≥99.6 |
≥99.6 |
≥99.6 |
≥99.6 |
≥99.6 |
|
Gan flow |
Nm3/h |
50 |
80 |
100 |
20 |
50 |
80 |
150 |
200 |
300 |
|
Gan purity |
Ppm(O2) |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
|
Operating ?pressure |
Mpa |
1.2 |
1.2 |
1.2 |
1 |
1 |
1 |
1 |
1 |
1 |
|
Start-up time |
hour |
≤12 |
≤12 |
≤12 |
≤10 |
≤10 |
