R25 Mining Crossover Coupling Rock Drilling Tools 150-170mm
- T/T L/C D/P D/A
- 7 days
You May Like
-
CNC Milling Drill Coupling R28 Threaded Coupling Wear Resistance
-
2.5 inch CNC milling Crossover Drill Coupling R28 160mm
-
Underground Mining R32 Drill Coupling 150mm 170mm 190mm Length
-
Tungsten carbide R32 Drill Coupling Crossover Coupling for Tunneling
-
R38 Underground Mining Drill Coupling With Heat Treatment Process 170-190mm
-
T38 190mm Threaded Drill Coupling , Long Hole Drilling Stone Drilling Tools
Product Details
| Brand Name | MIROC | Place of Origin | China | |
| Model Number | 4148300432-4148300435 |
Product Description
?
R25 Mining Crossover Coupling Rock Drilling Tools 150-170mm
?
Description
Crossover coupling using R25 thread system
.
? R25 thread system
? Widely used in drifting and tunneling
Color: Green or Based on Customer requirements
Material: Tungsten carbide and high strength alloy steel
Processing: CNC milling and proprietary heat treatment process
Type: R25 Crossover Coupling
?
Applications
? Underground Mining
? Tunneling
?
Competitive Advantage
High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance
?
specification
?
| Part?Number | Product?Code?and?Brief? | Length | Length? | Diameter? | Diameter? | Thread | Weight?(kg) |
| 4148300432 | CS-R25/R32-150,?R25? | 150 | 6???? | 45 | 1?7/9 | R25-R32 | 1.1 |
| 4148300433 | CS-R25/R32-160,?R25? | 160 | 6?2/7 | 45 | 1?7/9 | R25-R32 | 1.2 |
| 4148300434 | CS-R25/R38-160,?R25? | 160 | 6?2/7 | 56 | 2?1/5 | R25-R38 | 2.5 |
| 4148300435 | CS-R25/R38-170,?R25? | 170 | 6?2/3 | 56 | 2?1/5 | R25-R38 | 3.2 |
