15000BPH 4 in 1 Automatic Bottle Filling Machine For Soda Water

Brand Name	Jiayuan		Place of Origin	China
Model Number	CGF32-32-32-10

Delivery Time:30 days
Certification:CE,SGS

Automatic SUS304/316 15000BPH CGF32-32-32-10 4-in-1 drinking water filling machine

Quick Detail:

Capacity: 12000-15000 bottles per hour Sterilizing water rinser, pure water rinser, filler, capper 4-in-1 monoblock Fully automatic, no bottle no filling, no cap machine will stop. CE, ISO certificate Designed power supply: AC/380V/50HZ/3PHASE Customizable

15000BPH 4 in 1 Automatic Bottle Filling Machine For Soda Water

Description:

Automatic 4-in-1 Drinking water filling machine ?

Main Features

1).This?Drinking water filling machine is used to fill PET bottle pure water, mineral water, distilled water and other non gas beverage.

2).?This 4-in-1?Automatic Drinking water filling machine has the functions of chemical washing, bottle?pure water washing, water filling, and bottle capping.?This design reduces the time of water contact with outside. It improves the sanitation condition, increase the production capacity and economic efficiency.

3). It adopts hanging type conveying bottle structure to make changing different bottle sizes with less time and more convenient.

4).This drinking water filling machine use high quality food grade stainless steel material. All the material contact with water is Stainless Steel 304 (& stainless steel 316L according to customer\'s demands).

5).The whole machine is equipped with advanced PLC controlling system. Key electric element is from international well-known brand such as MITSUBISHI, OMRON, and SCHNEIDER.

6). Filling Capacity 2,000bph to 20,000bph for your choice.

7).?This?Drinking water filling machine model No. CGF32-32-32-10 filling capacity is 12,000-15,000bph.

Application

This machine can be used for filling non-carbonated liquid beverage with normal or middle temperature into PET bottles and capping it automatically.

Pure water Mineral water Juice filling with normal temperature or middle temperature.

Specifications:

Model:	CGF32-32-32-10
Capacity:500ml(b/h)	12000-15000
Suitable Bottle Height(mm)	150-320
Suitable Bottle Body Diameter(mm)	φ50-φ100
Suitable Cap Shape	Plastic Screw Cap
Power: (W)	8.63
Filling Temperature:	Room Temperature
Water Consumption for Washing Bottle(kg/hr)	3500
Gas Consumption(m3/min)	0.5
Size L×W×H (mm)	3500×2200×2250
Total Weight:(kg)	6000
Power Supply	380V/50HZ

Competitive Advantage:

The?three?functions?of?bottle?washing,?filing?and?capping?are?composed?in?one?body?of?the?machine. The?whole?process?is?automatic, no bottle no filling, no cap, machine will stop. So?this?machine?has?three?steps,?first?is?washing,?second?is?filling,?third?is?sealing?the?bottle.? Low?power?consumption,?better?material?SUS?304,?SUS?316. Small?size, simple?structure, low?investment Auto?complete?line,?need?less?worker.
