Three Phase General Electric Variable Frequency Drive AC VFD Drive 185KW 380V

FOB Price

Negotiable / Kilogram

1 Kilogram(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	POWTECH		Place of Origin	China
Model Number	PT200 185G/200P-3

Product Description

Delivery Time:5-7 working days
Certification:CE,ROSH,FCC

Three Phase General Electric Variable Frequency Drive AC VFD Drive 185KW 380V

Product features:

DC or AC input,3 phase AC output Full automatic working? motor parameter self-learning LED/OLED display--multi language? Double power design and best European componet Special design for high environment temprature and fluctuate voltage General 50/60Hz, 0.00 ~ 400.00Hz adjustable, 0.01Hz Precision? DSP chip,PLC function,terminal control,vector control,PC RS485 remote control

quick detail:

? ? ? ?Name ? ??	? ? ? ? ?Freuqency inverter? ??	? ? ??Brand?? ? ? ? ? ? ? ??	? ? ? ? ??POWTECH
Power	185KW	Voltage	380V±15%
Certificate	CE, RoHS, FCC	Rated Current	340/380A
Model Number	PT200 185G/200P-3	Place of Origin	Shenzhen China
IP	20	Output type	three phases
Delivery Time	5-7 working days	Price?	Negotiation
Supply Ability	2000pcs/Month	Packing Details	Carton case or Wooden case
Warranty	24 Months	Installation size	370935Φ14mm
Size?	1300400600mm	G.W.	189kg

Product Positioning:

The Powtech PT200 series inverter is a high-performance current vector inverter based on the European power and the latest control theoretical and technological achievements and combining with the latest market power technology application requirements, which introduces new high-performance current right amount inverter to control motor perfect by servo function for a comprehensive solution to the filed of high-end control

The Series inverter is a high-quality and multifunction vector control inverter . It can run a wide range of speed and torque control in high-precision by decoupling control of motor magnetic flux current and torque current torque :fast and accurately

High-end hardware platforms , scientific production technology and complete testing equipment make the product more stable and reliable

Description:

Power
Voltage and frequency level	Three-phase 380-415V,50/60HZ?
Allowable fluctuations	voltage:±15% frequency:±15%
Control?performance
Control system	DSP-based high-performance vector control inverter
Output frequency	G/P/Z/S/T/M type: 0.00-400Hz, the maximum frequency could be set on the range of 10.00Hz-400Hz
Control method	V/Fcontrol, open-loop magnetic flux vector control 1,open-loop magnetic flux vector control 2,PG vector control
Automatic torque boosting function	low frequency(1Hz)powerful output torque can be achieved under the V/F controlling
Accelerate/decelerate control	Segment S curve acceleration and deceleration set mode,maximum running time is 9600 hours
Program-runing control	16 segments speed running,maximum running time is 888.88 hours
Frequency setting accuracy	Digit:0.01Hz(below 300Hz),0.1Hz(above 300Hz);analogue:1% of maximum frequency
Frequency accuracy	Speed control tolerance 0.01%((25°C±10°C))

Performance Introduction:

1. Using DSP as the core of control unit to achieve high-speed high-performance control;

2. Way of speed control: SVC, VC, V/F control, torque control

3. Automatically idendtify the motor parameters, intelligent
