25KW Induction Melting Equipment heat treating For Smelting Aluminum / Bronze

25KW Induction Melting Equipment For Smelting Aluminum , Bronze 20KG

Quick Detail:

Specification

Model: GYM-25KW

Max output power: 25KW

Smelting weight of steel, iron: 8kg

Smelting weight of aluminum, bronze, and other precious metals: 20kg

Major features

1. Medium frequency induction heating machine adopts solid state IGBT frequency conversion control technologies, it has all kinds of protection control, giving signal under conditions of over-current, water shortage, overheating, overvoltage, short circuit, and phase missing, as a result, the reliability is greatly enhanced.

2. It has the function display of current, voltage, and timing, making the working condition easily perceived, and giving guidance to induction coil design, capacitance control.

3. Small size, light weight, requires no more than 1 sqm, and movable

4. Continuously heating for 24 hours

5. Low power consumption, with electromagnetic grinding capability, providing uniform smelting

Operating Principle

Frequency conversion electromagnetic induction heating or induction heating for short is a method for heating metal materials by converting power frequency power supply into that of specific range based on the principle of electromagnetic induction. It is mainly applicable to the metal hot working, heat treatment, welding and melting. This type of heating technique is also applicable to packing industry (such as sealing of aluminum foil used in medicine and food industry), semiconductor material (such as extruded monocrystalline silicon and heated affixing metal parts for auto glass).?

Basic components of induction heating system include induction coil, AC power source and work pieces. Induction coil can be fabricated into different shapes as per different heated objects. The coil is connected with the power source providing alternating current for coil. The alternating current possessed by the coil can create a alternating magnetic field passing through the work pieces to produce eddy flow as required by heating.

Advantages of Induction Heating Equipment

1. Fast heating: the minimum rate of heating is less than 1 second (rate of heating is available for adjustment and control).

2. Wide coverage of heating: it can be used to heat various metal parts (replace removable induction coil as per different operating switches).

3. Easy installation: it can be used once it is connected with power source, induction coil as well as water supply pipe and rising pipe; it is small in size and light in weight.

4. Easy operation: you can learn to operate it within several minutes.

5. Fast start-up: it can be started to perform heating operation on condition that water and power supply is available.

6. Low power consumption: As compared with convention
