House MBC Mini Circuit Breaker Automatic Reset Low Voltage 63A IEC60898

JL-EPN Series Mini Circuit breaker with 1P, 2P, 3P, 4P 1A to 63A has passed CE, ROHS

Quick Detail:

Place of Origin: Zhejiang, China (Mainland)

Brand Name: JIELI

Model Number: JL-EPN

Type: Mini circuit breaker

Poles Number: 1P,2P,3P,4P

Products: EPN

Current: 1A to 63A

Tripping curves: B, C, D

Operating voltage: up to 415 V

AC insulation voltage:500 V

Auxiliaries: shunt tripping, under voltage tripping, over voltage tripping

Breaking capacity:4.5KA, 6KA,10KA

Standards: IEC/EN 60898 or IEC/EN 60947-2, IEC60947-3

Insulation: Class 2

Description:

﹡JL-EPN?series mini circuit breaker is neoteric in structure, light in weight, reliable and excellent in performance.

﹡The frame and parts of JL-EPN mini circuit breaker adopt plastics of high fire resistant and shockproof.

﹡The product JL-EPN?series mini circuit breaker complies with IEC 60898 & GB10963-1999.

﹡JL-EPN mini circuit breaker has two kinds of functions: overload protection and short circuit protection.

﹡We are manufacturer of electrical products, mainly produces mini circuit breaker and residual current circuit breaker.

Applications:

JL-EPN?series mini circuit breaker is used in lighting distribution system or motor distribution system for protecting overload and short circuit in the system.

JL-EPN?series mini circuit breaker, with long life, is mainly used in AC 50Hz/60Hz single pole 240V or two, three, four poles up to 415V circuit for overload and short circuit protection, as well as for infrequently switching electric equipment and lighting circuit in normal case.

JL-EPN?series mini circuit breaker is used in residential building, non-residential building, energy source industry and infrastructure.

Specifications:

Competitive Advantage:

?The world\'s first supplier of MCB OJM servi
