Product Details
| Brand Name | FANRS MACHINERY | Place of Origin | China | |
| Model Number | FM 160 |
Product Description
Certification:CE,ISO
Scaffold Pipe Straightening Machine promote straightness and precision straightening
low noisy Seven Rollers Pipe Straightening Machine for All Metal / Steel Pipes
Introduction:
????? Our pipe straightening machine is designed by Japan Electric Corporation KUSAKABE
in 1990s,and made in Taiwan.By the introduction of equipment and production plant for many
years in straightening, we have many practical experience in pipe straightening,innovation,
development and improve the policy to create more than 17 roller precision steel roller
straightening machine.
?? ???Our pipe straightening machine is able to roll over for the big S-curve roller surface, double drive rotary tube forward to achieve the desired rotation to promote straightness and precision straightening.Straightening without scars,without internal cracks,smooth surface.
????? 1. Best machine for pipe straightening;
????? 2. high speed,low noisy;
????? 3. high accurate,easy to handle;
Specification:
|
No |
????????????? Items |
Parameters |
? Unit |
|
|
1 |
Straightening ??? Pipe |
Max.yield limit |
?? 580 |
? N/m㎡ |
|
Diameter |
? 50-160 |
?? mm |
||
|
Max.pipe thickness |
?? 15 |
? mm |
||
|
2 |
Straightening Speed |
? 6-26 M |
? M/min |
|
|
3 |
Straightening Roller |
Angle of Adjustment |
? 24-30 |
? Degree |
|
??? Roll Space |
?? 950 |
? mm |
||
|
?Throat Diameter |
?? 320 |
? mm |
||
|
??? Length |
?? 560 |
? mm |
||
|
4 |
???????? Upper Roll Adjust Range |
? 80-300 |
? mm |
|
|
5 |
Straightening Tortuosity for One time |
? ≤1.5 |
? mm |
|
|
6 |
Rising Speed of Rising Roller(Inching) |
?? 0.21 |
? mm/r |
|
|
?XCD??? 2.2-6-59 |
???? HJH/960P |
??? 2 |
? Set |
|
|
7 |
?? Speed Ratio |
????? 900r-70r |
??? 2 |
? Set |
|
Matching 55 Variable-frequency Drive |
||||
|
8 |
?????????? Main Transmission |
??? 2 |
? Set |
|
|
9 |
?? Main Motor |
?????? Model |
?Y315S-8 |
? (B3) |
|
?????? Power |
