industrial Roof Tile PPGI GB / ASTM Color Coated Steel Coil , 0.17mm-1.20mm

GB / ASTM Standard Color Coated Steel Coil ?0.12mm 1.50mm Thickness?

Quick Details:

Description:

1. Description: GB/ ASTM standard color coated stee

2. Standard: GB, ASTM

3. Thickness: 0.17mm-1.20mm

4. Width: 762mm-1250mm

5. Surface Treatment: Chromate-free passivation and oiled

6. Zinc Coating: 60g-200 GSM

7. Coating Technique?Double Coating double baking, Three Coating?Glossiness

8.

Pencil hardness≥ 2H;?

Bend 1800, ?

T≤ 3T ?Tensile strength(MPA)270-500;

Reverse impact(J)≥ 9 ?

MEK cleaning(times) ?Top: ≥ 100
Back: 50
Paint color?Ral No. Or Customized?Painting: Topside: 5microns primer+15microns polyester, Backside: 5-7microns primer epoxy
Temper
No. 1 Full hard(90HRB; G500-G550)
No. 2 Commercial Quality(70HRB, G300-G350)
Paint Thickness
Top coated 11-25μm
Back coated 7-15μm
Paint Thickness
Top coated 11-25μm
Back coated 7-15μm

Light yellow
Back color
Light gray
Thickness0.17-0.8mm
Width750-1250mm
Coil ID508mm
Coil weight3-7 tons
Surface processingCoated
Surface PaintEP, PE, PET, HDP, PVDF
Product Feature?Highly tensile, strong color fastness, good rainproof performance, continuous rolling, good corrosion resistance, easy installment and construction, easily removable, low cost

Applications:

Furniture: Wardrobe, office equipment, cooking appliance

Transport industry: Automobile components, bicycle parts, body of railway coaches

Other: water tanks, enamel, barrels, tubes, chimney, grain barn, stamping, cable wrapper, billboards, safety signs, pools

Products Advantage:

Specialize in producing with complicated equipments.

Strictly Quality Control

Reasonble price

delivery on time

attentive and meticulous service.

Specifications:

Competitive Advantage:

Jiangsu Lubo Trading and China National Investment Guaranty Co.Ltd products command a good market both at home and abroad which mainly exported to Middle east, and southeast Asia such as, Vietnam, Thailand, Egypt, Belgium, and other countries. With a reasonble price excellent quanlity and good service.

With the help of advanced technology and equipment advantages,

Devote ourselves to creat superior varieties of steel,

Innovated more mature automobile plate, home appliance plate, pipeline steel development processes and production technology
