Compressor cooling BOSCH Common Rail Test Equipment with flow meter 15KW (20HP)

Compressor?cooling BOSCH Common Rail Test Equipment with?flow?meter 15KW (20HP)

Quick?Details

Indication:?with?flow?meter

Test?injector?brand:BOSCH,?DELPHI,?DENSO,?SIEMENS

Usage:?Auto?Testing?Machine

Color:?green?blue?yellow?or?on?request

Power:?Electronic

1.?Main?motor?power: 15KW(20HP),18.5KW(25HP)；

2.?Working?voltage:?3?phase?220/380/415V,????50HZ/60HZ；

3.?Speed?range:?0—4000rpm；

4.?Supply?pressure?of?the?testing?fuel:?0—4bar；

5.?Fuel?tank?capacity:?80L；

6.?Currency?control?range:?0—3A；

7.?Injection?width?control?range:?100--3000μs；

8.?Injection?volume?range:?0.1ML—2000ML/1000times；

9.?Backflow?measuring?range:?6—400L/H；

10.?Pressure?control?range:?0—2000BAR；

11.?Fuel?temperature?range:?30--60℃；

12.?Cooling?method:?Compressor?cooling

13. Cooling?capacity:?5000KAL

Competitive?Advantage:

?ADM8719?common?rail?test?bench?is?our?latest?independent?researched?special?device?to?test?the?performance?of?

high-pressure?common?rail?pump?and?injector,?it?can?test?common?rail?pump?and?injector?of?BOSCH,?SIEMENS,?

DELPHI?and?DENSO.?It?tests?the?common?rail?injector?by?imported?high?precise?flow?meter?sensor,can?test?piezo

?injector.?It?controlled?by?industrial?computer?by?real?time.?The?data?is?also?obtained?by?computer.?19?LCD?screen?

display?makes?the?data?more?clear.?ADM8719?can?fulfill?the?remote?assistance?by?internet?and?make?the?

maintenance?easy?to?operate.?Advanced?technology,?steady?performance,?precise?measurement?and?convenient?

operation.?

Main?Characteristics:MAIN?FUNCTIONS:

1.?For?the?testing?of?the?common?rail?pumps?of?BOSCH?CP1,CP2,CP3,?DENSO?HP0,HP2,HP3,HP4,?DELPHI?and?

SIMENS

2.?Test?the?flow?control?valve?of?the?common?rail?pumps.

3.?Test?the?sealing?of?the?CR?injectors,?the?injection??flow?volume?under?full-loaded,?emission?point,?idling?and?the?

pre-injection,?also?back?flow?volume.

Main?parameters:

1.?Main?motor?power:15KW(20HP),18.5KW(25HP)；

2.?Working?voltage:?3?phase?220/380/415V,????50HZ/60HZ；

3.?Speed?range:?0—4000rpm；

4.?Supply?pressure?of?the?testing?fuel:?0—4bar；

5.?Fuel?tank?capacity:?80L；

6.?Currency?control?range:?0—3A；

7.?Injection?width?control?range:?100--3000μs；

8.?Injection?volume?range:?0.1ML—2000ML/1000times；

9.?Backflow?measuring?range:?6—400L/H；

10.?Pressure?control?range:?0—2000BAR；

11.?Fuel?temperature?range:?30--60℃；

12.?Cooling?method:?Compressor?cooling

13. Cooling?capacity:?5000KALTechnical?Specification:?
