DIN2391 Carbon Steel Mechanical Tubing For Automotive Hydraulic System

FOB Price

US$ 1.5 - 4.5/

1 (Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

SHENGDINGYUAN

Place of Origin

China

Product Description

Delivery Time:30 Days
Certification:TS 16949

DIN2391 Carbon Steel Mechanical Tubing For Automotive Hydraulic System

Description:?

Standard:DIN2391/C/EN10305-1/4 /SAEJ524/BS6323/4/JISG3445/ASTMA519 Size:OD:4-60mm,WT:0.5-6mm. Material:ST35,ST37.4,ST37,ST45,ST52,ST52.4,E235,E255,E355,SAE1010,SAE1020 Delivery State:NBK/GBK. Raw material:Bao Steel,Huai Steel,XingCheng Steel with good quality. Length:5.8m,6m. Package:Bundles or wooden cases. Surface Anti-rust:Both outside and internal tube surface flushing with anti-rust oil.

Synopsis of Process Routing:?Quality Carbon steel — Cold Drawn — Heat Treatment Without Oxidization (NBK Status) — Nondestructive Testing— Flushing The Internal Hole With Special Equipment Under The High Pressure —Dealing With Antirust Oil On Surface — Plastic Capping On Both Ends.

Quality:?

Surface roughness:Ra:0.8-1.3 um. Surface quality:very smooth and bright without oxide scale,pock,strach,crack and other defects. Internal hole Cleaness:clean without iron scrap,dust,better for hydraulic system life. Mechanical Properties:better extending rate and strength property,after bending with no deformation,after flattening and flaring process with no crack. Raw material:?Precision tubes are made from carbon steel from quality Bao Steel,XingCheng Steel,and HuaiSteel.

Tolerance Table of DIN2391?Carbon?Steel?Mechanical?Tubing?For?Automotive?

NAME	SCOPE(mm)	GB (mm)	DIN (mm)	Enterprise control(mm)	Special high-precision(mm)
Out Diameter	4-30	±0.1	±0.08	±0.05	±0.03
31-40	±0.15	±0.15	±0.05	±0.03
41-50	±0.20	±0.20	±0.08	±0.03
51-60	±0.25	±0.25	±0.08	±0.03
Wall thickness?	0.5-7	±10%,Min±0.12	±10%	±10%,Min±0.05	±10%,Min±0.03

Steel grades for DIN2391?Carbon?Steel?Mechanical?Tubing?For?Automotive?

Chemical composition(cast analysis)a
Steel grade	% by mass
Steel name	Steel number	C	Si	Mn	P	S
max.	max.		max.	max.
? ? ? ?? ST35	1.0305	0.17	0.35	≥0.40	0.025	0.025
?ST45	1.0408	0.21	0.35	≥0.40	0.025	0.025
?ST52	1.0580	0.22	0.55	≤1.60	0.025
