Plastic Injection Mold Guide Bushing Collar with Spiral Oil Groove

Brand Name	CIVADA		Place of Origin	China
Model Number	LC-P012

Delivery Time:5~7workdays after the order confirmed
Certification:IAF

Plastic Injection Mold Guide Bushing Collar with Spiral Oil Groove

1.?Material ?

SUJ2?(?52100?)(?1.2067?)?equivalent?

20Cr??(?5120?)?(?20Cr4?)?(?SCr435?)??equivalent ?

2. Hardness?

58?HRC?~?62?HRC?

3.?Specifications?

Standards?:?MISIMI?/?DIN?/?AISI?etc. Mounting?method?flange?fixing? Further?dimensions,?lengths?and?materials?available?on?request Customized?sizes?are?accepted Service:?OEM?available?,?and?standard?with?stock Tolerance?:?press-fit?part:?m5,?sliding?part:-0.001?~?-0.005mm,?Head?:?-?0.2?~?-?0.1mm?? Diameter?arrage?:??Φ?8.0mm??~??Φ?120?mm?or?according?to?customer’s?demand?. Polishing:?can?make?close?to?Ra?0.4?standard?is?R0.8 Good-quality?and?precision Nitrogen?treatment?to?improve?the?hardness ?More?products?can?be?produced?according?to?PUNCH?/?DANLY?/?DME?/?HASCO?/?TOHATSU?/?FIBRO?/?AGATHON?/?STRACK?/?PEDROTTI?/?RAYMOND?/?FUTABA?/?SANKYO?/?PROGRESSIVE?/?RABOURDIN?,?etc.

4. Machinery?&?Equipments

CNC?machining?center;?CNC?lathe;?Normal?lathe;?CNC?milling?machine; General?punching?machine,?CNC?turning?center;?Wire?EDM,?etc.? And?we?also?can?offer?4?or?5?axis-CNC?center?processes. General?milling?machine;?General?drilling?machine;?General?planning?and?grinding?machine?

5. About?Leader?Components?

(1?)?Introduction

Guide?Pillar?is?mold?and?die?components?to?be?used?in?combination?to?ensure?precise?positioning?activities?

guide?travel?guide?elements?mold.

Guide?Bushes?/?Guide?Sleeves?

Mold?parts,?used?in?conjunction?with?the?guide?posts,?play?a?guiding?role?in?general?with?the?gap?is?very?

small,?less?than?the?0.05mm;

Material?of?guide?pillars?generally?used?in?bearing?steel,?hot?die?steel,?easy?to?iron,?etc.,?and?to?the?amount

?of?bearing?steel?SUJ2?larger,?so?that?the?guide?post?in?durability?and?performance?can?change?sexual?

orientation?is?greatly?enhanced.?Guide?column?with?components?outside?the?guide?column?components?and

?assemblies?within?the?guide?column,?with?a?beautiful?metallic?luster.

Pillar?shoulder?belt?is?generally?cylindrical,?generally?have?oil?groove,?the?number?of?oil?groove?of?the?guide?

post?with?lengthened?degree?increases,?up?to?the?limit?tank?is?generally?8.

(2) Classification

Guide?Pillars,?in?accordance?with?the?use?of?different?places,?divided?into:?automotive?mold?guide?column,?

an?independent?guide?posts,?guide?posts?with?mold,?stripper?plate?with?guide?posts.?Not?the?same?in?

accordance?with?the?direction?of?the?guide?is?divided?into:?slide?guide?column?(Code?SGP),?rolling?guide?

column?(Code?SRP).?Follow?the?installation?in?a?different?way,?divided?into:?loading?type?push?type?pillar?and

?pillar.

(3)?Angle?pins?

Oblique?angle?pillar?mold?often?used?typically?20?degrees?or?25?degrees?two?tilt?angle?of?20?degrees?

generally?use?this?kind,?if?the?length?of?the?slider?is?moved?a?little?distance,?you?can?adopt?this?kind?of?25?

degrees.?If?the?distance?is?longer,?then?we?would?use?hydraulic?or?pneumatic?methods.

(4)?Center?hole

Roundness?pillar?there?is?a?very?high?demand,?primarily?playing?center?hole?in?order?to?use?cylindrical?

grinder?grinding?diameter,?because?the?use?of?the?outside?diameter?of?the?cylindrical?grinder?grinding?time?

to?use?the?top?center?hole?of?the?guide?post?withstand?rotation?before?You?can?grind.

6 . Machinery?&?Equipments

CNC?machining?center;?CNC?lathe;?Normal?lathe;?CNC?milling?machine; General?punching?machine,?CNC?turning?center;?Wire?EDM,?etc.? And?we?also?can?offer?4?or?5?axis-CNC?center?processes. General?milling?machine;?General?drilling?machine;?General?planning?and?grinding?machine?

?
?
7.? Further?Information

Testing? machine	Digital?Height?Gauge,?caliper,?Coordinate?measuring?machine,?projection?machine, ?roughness?tester,?hardness?tester?and?so?on.
QC	?1)?Technicians?self-check?in?production ?2)?Engineer?spot?check?in?production ?3)?QC?inspects?after?mass?production?finished ?4)?International?sales?who?were?trained?the?technical?know-how?spot?check?before?shipping
Main?Markets	North?America,?South?America,?Eastern?Europe?,?West?Europe?,?North?Europe,? South?Europe,?South?Asia,?Africa?Africa
