KT1426 Fire Alarm Cables 22 AWG FPLP-CL2P PVC Insulation Plenum
Negotiable
/ Kilogram
1 Kilogram(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
PVC Plenum Fire Alarm Cables 18 AWG 4C Shielded Red Cables
-
PVC 18 AWG CCS Bonded CATV Coax Cable MATV CCTV Black Coaxial Cable
-
50 Ohm Low Loss Signal Coaxial Cable , 100 Copper Conductor Cable
-
FTTH Drop Cable Fiber Optic Cable G.652D/G.657A 1/2/4 Core LSZH
-
2 Core Silicone Fire Resistant Cable , Low Smoke Fire Alarm Cable With Copper Conductor
-
Nickel BNC Coaxial Cable Connectors With Gold Plated for Radio / TV
Product Details
| Brand Name | KINGTONE OR OEM | Place of Origin | China | |
| Model Number | FPLP 22 AWG |
Product Description
Certification:ISO,CE,RoHS,UL
KT1426 Fire Alarm Cables 22 AWG FPLP-CL2P PVC Insulation Plenum
Quick Details
FPLP 22 AWG Fire alarm cable Solid Copper conductor? unshielded types: 4C shielded types: 4C Plenum PVC 500ft , 1000ft Fire power limited cableDescription
KINGTONE ELECTRONICS is the leading manufacturer of fire alarm system cables?for the fire protection industry. Our innovative product line includes all?power-limited cables for use in the NEC Article 760.?
NATIONAL ELECTRIC CODE (NEC) ARTICLE 760: NEC Article 760 covers the installation?of wiring and equipment of fire alarm systems,including all circutis controlled ?and powered by the fire alarm system.
These systems are defined in the NEC as?\" The portion of wiring system between the load side of the overcurrent devices?or the power-limited supply and the connected equipment of all circuits powered?
and controlled by the fire alarm system.\"
Type FPLP-FPLP power-limited fire alarm cable is listed by the NEC as being suitable for?usein ducts,
plenums and other space used for enviromental air. All FPLP cable are listed?as having adequate
fire resistant and low-smoke producing characteristics and must pass both?UL 1424
and UL stiener tunnel test 910
|
KT1426?Fire?Alarm?Cables?22AWG?FPLP-CL2P PVC?Insulation?Plenum |
|||||||
| Application | |||||||
| Indoor?for: | |||||||
| Audio?Circuits | |||||||
| Control?Circuits | |||||||
| Initiating?Circuits | |||||||
| Notification?Circuits | |||||||
| ? | |||||||
| Properties | |||||||
| Temperature?Rating:????\'-20?to?75℃ | |||||||
| Operating?Voltage:???????300?Volts?max. | |||||||
| Flame?Rating:??????????????UL?910,NFPA?262,C(UL)?FT6 | |||||||
| Insulation?&?Jacket:??????Plenum?PVC | |||||||
| Shielded?types | |||||||
| Conductors | NOM.THICKNESS(MM) | Nominal0.D.? | Capacitance | Impedance | DC?Resistance | ||
| Number | Solid | Insulation | Jacket | Inch | pf/ft | Ohms | Ohms/M\' |
| 4 | 22?AWG | 0.007\" | 0.015\" | 0.126\" | 53 | 38 | 17 |
| ? | |||||||
| ??Drain?Wire | ????22?AWG?Solid?Tinned-Copper | ||||||
| ??Shield | ????0.001\"?thick?Aluminum/Mylar | ||||||
| ? | |||||||
| Color | |||||||
| Number | Description | ||||||
| 4 | Blk,Red,Ylw,Grn | ||||||
| Order?Informations: | |||||||
|
KINGTONE?KT1426?×C22?E×××××××(UL)?FPLP?OR?CL2P?C(UL)US?FT6?SUN?RES(ROHS)?××××FT ? ? ? ? ? ? ? ? ?? DEVICE/ZONE?A?B?C?D?E?F?1?2?3?4?5?6?7?8?9 |
|||||||
| Packing | 1000FT/Pull?Box,?1000FT/Spool,?Pallet |
Competitive Advantage:
1, ?From raw materials to final products, we perform intense quality checks to maintain our product quality:
? ? ?A, Incoming material inspected by QC.
? ? ?B, Manufacturing Process Control
? ? ?C: Workers trained daily/weekly/monthly
? ? ?D: Work instructions manual at each work station
? ? ?E: 5S system implemented
? ? ?F: Machine maintenance procedure
? ? ?G: Quality Control and Final Inspection?
? ? ? ? ?The QC staff will check the material, process product
? ? ? ? ?and final product according to the specification or test procedure.
2, Our R&D efforts center on reinforcing and developing element technologies
? ? needed to support the future growth and success for customers and KINGTONE.
3, We know customers have urgent needs.
? ? We are skilled at effective communication to interact with customers.
? ? In order to provide prompt service, we can answer for you
