Stainless Steel Induction Annealing Machine , 160KW Induction Heating Equipment
- T/T L/C D/P D/A
- 7 days
You May Like
-
300KW Super Audio Frequency Induction Melting Furnace Heating Equipment Machines
-
25KW Super Audio Frequency Induction Induction Heating Apparatus Device for Quenching
-
Hot Fitting Medium Frequency Induction Heating Furnace Equipment Machinery 40KW
-
25KW Medium Frequency Induction Heating Equipment for Quenching, Annealing
-
25KW Induction Melting Equipment Heat Treating For Smelting Aluminum / Bronze
-
Quenching Steel Induction Hardening Machine With Induction Heat Treatment Equipment
Product Details
| Brand Name | GY | Place of Origin | China | |
| Model Number | GY-160AB |
Product Description
Certification:CE, SGS , ROHS
160KW Induction Heating Machine for Stainless steel online annealing
Quick Detail:
|
Name |
160KW Induction Heating Machine for Stainless steel online annealing |
Application |
Stainless steel online annealing |
|
Work power |
340V-430V |
Out power |
160KW |
|
Product size |
main : 1000x695x1100mm |
Certificate |
CE,SGS |
|
transformer : 870x430x750mm |
Specification
|
Model? |
GY-160AB (Three phase) |
|
Work power |
340V-430V |
|
Maximum input current? |
240A |
|
Output power? |
160KW |
|
Fluctuating frequency? |
30-80KHZ |
|
Output current |
400-6500A |
|
The flow rate of cooling water |
0.08-0.16Mpa 15L/Min |
|
Water temperature protection point? |
50C |
|
Product size? |
main : 1000x695x1100mm |
|
transformer : 870x430x750mm |
|
|
Net weight??? |
main : 155kgs |
|
transformer : 95kgs |
Major features:
1. 160KW Induction Heating Machine for Stainless steel online annealing adopts the most advanced MOS, IGBT frequency conversion control technologies to ensure the high efficiency and maximum output power.
2. 160KW Induction Heating Machine for Stainless steel online annealing it has the constant current and power control function, which can significantly optimize metal heating process, realize the high efficient and fast heating and bring into play the superior performance of the products.
3. 160KW Induction Heating Machine for Stainless steel online annealing has the function of three-stage time setting represented by heating-heat preservation-cooling. Furthermore, the power for heating and heat preservation is available for independent regulation, which can facilitate the heating and heat preservation, which is applicable to places requiring bulking and repeated heating.
4. A maximum ten types fault protection and display of over-current, over-voltage, water shortage and phase missing can provide higher reliability and durability.
5. It is safe and reliable, and requires no equipments of ten thousand voltage, and thus can ensure the safe operation.
6. The comprehensive full load design is available for 24-hour continuous operation.
7. 160KW Induction Heating Machine for Stainless steel online annealing is available for ultraviolet temperature detection, which can realize the automatic control of temperature, improve the heating performance and simplify the manual operation.
Applications
1. Heating (hot forging, hot fitting and smelting)
? Hot forging aims to fabricate the work pieces of certain temperature (different materials require different temperatures) into other shapes through forging press with the help of punch press, forging machine or other equipments, for instances, hot extrusion of watch case, watch flan, handle, mold accessory, kitchen and table ware, art ware, standard part, fastener, fabricated mechanical part, bronze lock, rivet, steel pin and pin.
?? Hot fitting refers to the connection of different metals or metals with nonmetals through the heating based on the principle of hot expansion or hot smelting, for instances, embedded welding of copper core of computer radiator with aluminum sheet and speaker web, compound of steel and plastic tube, sealing of aluminum foil (tooth paste peel), motor rotor and sealing of tubular electric heating element.
? Smelting mainly aims to melt the metal into liquid by using the high temperature, which is mainly applicable to the smelting of iron, steel, copper, aluminum, zinc as well as various noble metals.
