Product Details
| Brand Name | Encore | Place of Origin | China | |
| Model Number | EJC-H |
Product Description
5 ton, 7 ton, 10 ton Heavy-Duty Free Standing Jib Crane For With Electric Wire Rope Hoist For Warehouses / Storage Yard
?
Applications:
EJC-H Type Heavy-duty Jib Crane is widely used to control or position the load in an area that is generally inaccessible to material handling equipment, or where the load, weight or duty cycle make it impractical to employ manual rotation.
EJC-H Type Heavy-duty Jib Crane is designed to provide reliable, long-life performance with minimal maintenance.
Description:
This kind of crane is small and medium size lifting equipment, safe, reliable, high efficiency, energy-saving, time-saving and labor-saving and flexible feather, in the three-dimensional space and can operate freely, especially in the short, intensive lifting showing the occasion better than any other conventional lifting equipment unique advantages, widely used in workshops, warehouses, terminals and other fixed location.
EJC-H Type Heavy-duty jib crane is extended from frees tanding jib crane. It adopts slewing ring and sectional arm structure. The hoisting height can reach 2.5-6M. The slewing radius can reach 7-12M.
?
Specifications:
|
Type |
Capacity |
Lifting?speed |
slewing?angle |
L(m) |
R1(m) |
R2(m) |
h(m) |
|
EJC-H?1(7-12) |
1000kg |
8m/min |
360 |
7-12 |
6.8-11.8 |
1.5 |
2.5-12 |
|
EJC-H?2(7-10) |
2000kg |
8m/min |
360 |
7-10 |
6.8-9.8 |
1.5 |
2.5-12 |
|
EJC-H?2(7-12) |
2000kg |
8m/min |
360 |
11-12 |
10.8-11.8 |
1.5 |
2.5-12 |
|
EJC-H?3(7-10) |
3000kg |
8m/min |
360 |
7-10 |
6.8-9.8 |
1.5 |
2.5-12 |
|
EJC-H?3(11-12) |
3000kg |
8m/min |
360 |
11-12 |
10.8-11.8 |
1.7 |
2.5-12 |
|
EJC-H?5(7-10) |
5000kg |
8m/min |
360 |
7-12 |
6.8-11.8 |
1.7 |
2.5-12 |
|
EJC-H?7(7-10) |
7000kg |
7m/min |
360 |
10 |
7 |
2 |
3-8 |
|
EJC-H?10-5 |
10000kg |
7m/min |
360 |
5.4 |
5 |
2 |
3-5 |
