32channels CTcP/UV-CTP Prepress Printing Machine for Sale, High Presicion 405nm Laser Diode

Brand Name	DOIE		Place of Origin	China
Model Number	CTCP 32channels platemaking prepress machine

Delivery Time:45days
Certification:ISO9001

1. Name: 32channels CTcP/UV-CTP prepress printing machine for sale, high presicion 405nm laser diode

2. Application: Prepress Printing Area
3. Feature:? Qaulity laser,electric structure,hand script guide rail

Description:

Professional DOIE manufacturer for plate making machine. CTcP 48 channels is UV type of DOIE CTP products which uses 405nm laser diode to condensate..

X-0482U ?CTcP machine with temperature control system increase stablility on laser,which can keep constant fittable temperature of laser, improve laser lifelong and

Decrease laser wastage.

Unique and professional design for plate edge testing system which is made of high precision? side guild ?technology and plate edge sensor together to make sure the plate feed in the totally centor position.

Specifications

Model	X-0322U
Light Channels	32
Output Speed(P/h)	17
P size:1030mm×800mm
29
P size:510mm×400mm
Light Source	405 nm Laser Diode
Output Resolution (dpi)	2400
Dot Reproduction	1%～99%
Register Accuracy (mm)	＜0.01
Plate Size (mm)	Max. 1160×940；Min. 450×320
Suitable Plates	Various UV-CTP(CTcP) plates
Plate Thickness (mm)	0.15~0.30
Plate Loading and Unloading	Loading:Automation(Standard Set) Unloading:Automation Vacuum Fixation
Plate Position Accuracy (mm)	0.2
Plate Balance	Automatic Balance
Data Interface	USB,1000Mbit/s
Ambient	Temperature 25℃±3℃ Humidity 20~80%(Non-condensing)
Machine Dimension (mm)	L2200×W1100×H1050
Net Weight (kg)	1500
Power Supply	≤6KW/220V±5%,50/60Hz

Applications:

CTP computer to plate machine with bridge ,conveyor,stacker together to make of integral prepress printing system, DOIE develop auto loader to reduce labor cost for

Customer also. CTcP plate is very low cost to instead of imagesetter.

Competitive Advantage:

1. Precise guiderail chassis. Manual entire scrape.

The chassis is HT300 inblock cast, guiderail and chassis became in one, the high mechanical strength, the high heat stability, less possibility of deformation. The guiderail precision could achieve 1-3μm/m,effectively ensure printing precision. Scraping guiderail is made by cast-iron, the surface has one thin oil slick, play an lubricant, protective role; Using import soft guide pairs and precise grinder guiderail technology, make optical platform move has little wear; the moving of platform has better smooth, precision.

2. Independent vacuum structure, effectively absorb various plates.

By using the three-cavity technology, the drum could effectively absorb various plates, avoid the plate. According to different size of plate, adjust absorptive power, could achieve best printing effect. Using negative pressure checking before printing, avoid the plate flying. Using negative pressure checking in printing, avoid the plate flying. Using negative pressure and prevent air leakage technology.

3. Continue feeding plate system, achieve automatic loading plate.

Using advanced belt conveying plate system. Using mechanical head clip aut
