Double Row Tapered Roller Bearings 351172, 351976, 651076 For Radial Loading
Negotiable
/ Set
1 Set(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Double Row Tapered Roller Bearings 351080, 351180, 351984, 351084 With Sliding Surfaces
-
Double Row Tapered Roller Bearings 351996, 3519 / 500, 3510 / 500 For Axial Loading
-
Four Row Double Row Tapered Roller Bearing 3519 / 750X2 With Inner Ring For Axial Load
-
Double Row Tapered Roller Bearing 687 / 672D, 861 / 854D With Inner Ring For Radial Load
-
Double Row Tapered Roller Bearing 99575 / 99102CD, 31330X.K11 For Radial Load
-
Double Row Tapered Roller Bearings 173KH350+K, HM237546DW With Thicker Side of The Cup
Product Details
| Brand Name | HONGSHI | Place of Origin | China | |
| Model Number | Various standard are available |
Product Description
Certification:ISO
?Double Row Tapered Roller Bearings 351172, 351976, 651076 For Radial Loading
| Model | Old Model | Boundary dimensions (mm) | Structure | Calculating coefficient | Basic load ratings (KN) | Speed ratings (r/min) | Weight (KG) | |||||||||||||
| d | D | T | C | B | b | D1 | Rsmin | rsmin | e | Y1 | Y2 | Y0 | dyc_Cr | stc_Cor | Grease | |||||
| 351172 | 1097772 | 360 | 600 | 242 | 170 | 106 | - | - | 5 | 1.5 | 1 | 0.44 | 0.54 | 2.3 | 1.51 | 3100 | 6800 | 400 | 520 | 221 |
| 351976 | 1097976 | 380 | 520 | 145 | 105 | 65 | - | - | 4 | 1.1 | 1 | 0.38 | 1.77 | 2.64 | 1.73 | 1510 | 3800 | 530 | 710 | 78.8 |
| 651076 | 97176 | 380 | 560 | 190 | 140 | 82 | - | - | 5 | 1.3 | 1 | 0.3 | 2.29 | 3.4 | 2.24 | 2620 | 4300 | 410 | 540 | 135.2 |
| 351176 | 109776 | 380 | 620 | 242 | 170 | 106 | - | - | 5 | 1.3 | 1 | 0.46 | 1.47 | 2.18 | 1.43 | 3100 | 6850 | 410 | 5540 | 250 |
Feature:
???These bearings have tapered rollers which are guided by the thicker side of the cup. The design of the sliding surfaces of the cup and inner ring and the rolling elements when extended converge towards the same single point on the bearing axle. bearing tapered
??? Double-row and four-row taper roller bearings can bear the radial load and axial load in double directions.
