Double Row Tapered Roller Bearing 352140, 352240 For Axial Load With Rolling Elements
Negotiable
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
352948, 352948X2 Double Row Tapered Roller Bearing For Axial Load With Rolling Elements
-
Double Row Roller Bearings 352968X2, 352968 With Tapered Rollers For Radial Loading
-
Double Row Tapered Roller Bearings 351068,351168 With Sliding Surfaces of The Cup And Inne
-
97872, 351072, 352072 Double Row Tapered Roller Bearing For Axial Load in Double Direction
-
Double Row Tapered Roller Bearings 351172, 351976, 651076 For Radial Loading
-
Double Row Tapered Roller Bearings 351080, 351180, 351984, 351084 With Sliding Surfaces
Product Details
| Brand Name | HONGSHI | Place of Origin | China | |
| Model Number | Various standard are available |
Product Description
Certification:ISO
?Double Row Tapered Roller Bearing 352140, 352240 For Axial Load With Rolling Elements
| Model | Old Model | Boundary dimensions (mm) | Structure | Calculating coefficient | Basic load ratings (KN) | Speed ratings (r/min) | Weight (KG) | |||||||||||||
| d | D | T | C | B | b | D1 | Rsmin | rsmin | e | Y1 | Y2 | Y0 | dyc_Cr | stc_Cor | Grease | |||||
| 352140 | 2097740 | 200 | 340 | 184 | 150 | 82 | - | - | 3 | 1 | 1 | 0.25 | 2.74 | 4.08 | 2.68 | 1650 | 3400 | 800 | 1100 | 63.8 |
| 352240 | 97540 | 200 | 360 | 218 | 174 | 98 | - | - | 5 | 1.1 | 1 | 0.41 | 1.66 | 2.47 | 1.62 | 2240 | 4230 | 800 | 1100 | 90.9 |
| -? | 37741 | 205 | 320 | 150 | 110 | 75 | - | - | 3.7 | 1.3 | 2 | 0.39 | 1.72 | 2.56 | 1.68 | 730 | 1610 | 940 | 1100 | 40.2 |
| 352944 | 2097944 | 220 | 300 | 110 | 88 | 48 | - | - | 3 | 0.8 | 1 | 0.31 | 2.18 | 3.24 | 2.13 | 640 | 1720 | 810 | 1100 | 21.2 |
Feature:
???These bearings have tapered rollers which are guided by the thicker side of the cup. The design of the sliding surfaces of the cup and inner ring and the rolling elements when extended converge towards the same single point on the bearing axle. bearing tapered
??? Double-row and four-row taper roller bearings can bear the radial load and axial load in double directions.
