PVC / U-PVC / C-PVC Pipe Extrusion Line SJ-45 / SJ-65 For Water Supply

PVC / U-PVC / C-PVC Pipe Extrusion Line SJ-45 / SJ-65 For Water Supply

Quick Detail:

PVC Fiber Reinforced Soft Pipe Production Line

Pipe diameter:8-63mm
Useful material:PVC?

Certification: ISO9001-2000；CE

PVC Steel Wire Reinforced Soft Pipe Production Line

Pipe diameter:12-75mm
Useful material:PVC?

Certification: ISO9001-2000；CE

PVC Fiber Reinforced Soft Pipe Production Line , PVC Fiber Reinforced Soft Pipe Extrusion Line

PVC Fiber Reinforced Soft Pipe Extruding Machine , PVC Fiber Reinforced Soft Pipe Making Machine

PVC Steel Wire Reinforced Soft Pipe Production Line , PVC Steel Wire Reinforced Soft Pipe Extrusion Line

PVC Steel Wire Reinforced Soft Pipe Extrusion Machine , PVC Steel Wire Reinforced Soft Pipe Making Machine

Description:

PVC Fiber Reinforced Soft Pipe Production Line

This series of extrusion lines are mainly used to produce PVC drainage pipes and U-PVC,C-PVC water supply pipes.

Advanced design for screws supplies powerful safeguard for the PVC plasticization.

Unique inside oil controlling temperature system adapts different technology formulas.

Beautiful and practical stainless steel body for the vacuum calibration and spray cooling system, unique multi-section vacuum system ensures the stable sizing and cooling for pipes; special spray cooling system improves the cooling efficiency ; special water position, water temperature system make the machine more intelligent.

Hauling-off unit adopts particular pedrail structure, which is easy and convenient for operation; pedrail clamping uses mechanical and pneumatic combining system, which is more reliable.

Cutting system adopts saw blades and planetary cutting means; sumping uses hydraulic system , which ensures the smooth cross section; equipped with dust-collecting unit, which ensures the clean working environment.

Raw?material + additive → mixing → granulating → conveying?feeding → single?screw?extruder → extruding?mould → spray?cooling?water?tank →belt?haul-off → fiber?winder → warm-up?oven → single?screw?extruder → mould → spray?cooling?water?tank → belt?haul-off → meter?measure → winder → finished?product?inspecting & packing

PVC Steel Wire Reinforced Soft Pipe Production Line

This line is suitable for producting PVC Steel Wire Reinforced Flexible Pipe. The wall thickness is transparent flexible PVC material, inside is spiral steel wire, the superiority of which includes Crushing Resistance,Corrosion Resistance, Antistatic and Good Liquidity, etc. suitable for supplying high-pressure and flammble gas or fluid. This kiind of pipe is mainly used in the line of Mechanism, Chemical, Construction, Agricultrual Irrigation and Vacuum Equipment, etc.

Applications:

The PVC Fiber Enhancing Soft Pipe, called gridding pipe and snakeskin pipe which is mainly used to convey the middle pressure or corrosive gas and liquid, it is widely used in such areas as mechanical engineering, coal mine, petroleum, chemical industry, agriculture irrigation, civil application(solar energy water heater, gas-jar), also it can be used in irrigating garden and lawn.

The PVC soft pipe with steel wire reinforcing. The pipe wall is soft PVC plastic, in which there are spiral steel wires. The pipes have the strong point of pressure and corrosion resistance and antistatic. It is used to convey the pressure or corrosive gas and liquid, vent impure liquid. It is widely used in such areas as mechanical engineering, chemical industry, architecture, agriculture irrigation, vacuum device and dust collector soft pipe.

Specifications:

PVC Fiber Reinforced Soft Pipe Production Line
