RG59 Tri-shield Coaxial Cable, 75 ohm Drop Cable for CATV Systems, RG59 Coaxial Cable

Brand Name	Libo		Place of Origin	China
Model Number	RG59CU tri-shield 0.16x112

Delivery Time:Within 10 days
Certification:CE, ISO9000,ISO14001,RoSH,Certificate of Network access of Broadcast equipment, State Administration

RG59 Tri-shield Coaxial Cable, 75 ohm Drop Cable for CATV, CCTV Systems,? RG59 Coaxial Cable
?
Product description:
Inner conductor is bare solid copper. Dielectric core is insulating grade virgin polyethylene. The 1st shield is bonded laminated aluminum tape, the second shield is 95% tinned copper braid, the third shield is normal aluminum foil. Outer jacket is PVC flame retardant jacket or PE for outdoor application.
?
Center conductor:
20AWG copper clad steel
Nominal diameter: 0.32inches (0.81mm)
?
Dielectric:
Gas expanded polyethylene
Nominal diameter over dielectric: 0.144inches (3.66mm)
?
Shield:
1st shield: laminated aluminum tape bonded to the dielectric.
Nominal diameter over tape: 0.151inches (3.84mm)
2nd shield: tinned copper braid, 0.16x7 ends x16 carry, pitch is 25mm, 95% coverage.
3rd shield: normal aluminum foil.
?
PVC Jacket:
Nominal diameter over jacket: 0.24inches (6.10mm)
Nominal jacket thickness: 0.032inches(0.81mm)
?
Electrical properties:
Impedance : 75±3 ohms
Velocity of propagation: 85% nominal
Attenuation@ 68OF(20oC):

@Frequency MHZ	dB/100 meters(MAX.)
5	2.82
55	6.73
211	12.47
250	13.45
350	15.75
450	17.72
500	18.70
600	20.43
750	22.87
865	24.67
1000	26.64
1450	32.41
1800	38.72
2200	42.78

Applications:
RG59 tri-shield cable is used as a distribution cable for indoor CATV, CCTV systems and as a connection cable for satellite systems where lower attenuation required.
Competitive Advantage:

RG59 tri-shield cable has outstanding anti-interference effectiveness and excellent transmission reliabilities. RG59 tri-shield cable is of low cost, and it is easy to install as well. Libo cable was established in 1994, it is subsidiary of Libo group which is one of the 500 largest private enterprises in China. Libo cable has a stable workforce and engineering team, normal lead-time for 40’ FCL is around 10 days. Libo cable is equipped with a Provincial-level Research and Development Center, we offer OEM service as well as ODM service.
