Best, Small, Benchtop, Home PET Injection Molding Machine Equipment HW160 for Sale

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HANVOS		Place of Origin	China
Model Number	1

Product Description

Delivery Time:20days

Best, Small, Benchtop, Home PET Injection Molding Machine Equipment HW160 for Sale

Plastic injection molding machine is an important equipment which can inject hot plasticity plastic and hot getting firm plastic after heating and making various kinds of plastics products. The plastics industry is a new developing industry, though the developing history of injecting molding machine is still very yong, With the development of sciece and technology , the plastic injection molding machine have already developed into a relatively ripe machines. HW series machine is reseachine is researched, developed, making, selling all by oneself since the company established. HW series is exactly representative of machines, which can satisfy user\'s processing of various kinds of ordinary products.

MODEL	HW-160
FIXED?PUMP
INJECTION??UNIT	SCREW?TYPE	UNIT	A	B	C
SCREW?DIAMETER	mm	38	42	45
SCREW?L/D?RATIO	L/D	23.2	21	19.6
SHOT?VOLUME	cm3	278	339	390
SHOT?WEIGHT	g	253	308	355
INJECTION?PRESSURE	Mpa	213	174	152
MAX.?SCREW?SPEED	rpm	163
CLAMPING?UNIT	CLAMPING?FORCE	kn	1600
SPACE?BETWEEN?TIE-BAR	mm	455*435
OPENING?STROKE	mm	415
MOULD?THICKNESS	mm	150-450
HYDRAULIC?EJECTION?FORCE	kn	38
HYDRAULIC?EJECTION?STROKE	mm	150
NO.?OF?EJECTOR?PINS	pc	5
OTHERS	HEATING?CAPACITY	kw	9.5
PUMP?MOTOR	kw	15
HYDRAULIC?SYSTEM?PRESSURE	Mpa	16
OIL?TANK?CAPACITY	L	310
MACHINE?DIMENSION(LWH)	M	51.42
MACHINE?WEIGHT	T	4.7
