8mm SMD LED Screen Signs , 1R1G1B Advertising Led Display Panel

Brand Name	UHLED		Place of Origin	China
Model Number	P8mm

Delivery Time:15days
Certification:CE, CCC, FCC, ROSH, ISO9001

8mm SMD LED Screen Signs , 1R1G1B Advertising Led Display Panel

Quick Detail:

(1) Computer control with software

(2) High resolution, top vision

(3) Show images, videos, texts, messages......

(4) 2-5 years warranty

Features:

(1) Brightness adjustable

(2) High Refresh Rate reach to 3000Hz or more

(3) Long lifespan and stable quality

(4) Working under the temperature -30C to +75C

(5) Save 35% power than normal screens

Application:

advertising LED display, shopping mall LED display for logo showing , bank & stock exchange LED display for rates showing , train & bus station , airport , telecommunication LED screen system for information showing and instruction , Stage performances and so on.

Function:

Excellent visual effect, clear and exquisite Good flatness. Easy to clean, welding spots inoxidizable. Closer look available, better effects without glare and mosaic. Good viewing angle. Easy to assembly, install and transport with simple packing and convenient use. Vivid mixed colors. No color cast when look from different angles. Excellent heat-sinking, high stability, no scrapped lamp.

About UHLED:

We are the professional and famous Manufacturer of LED screen in Shenzhen, China. We have exported to North America, Europe, South America, Middle East, Central Asia and many other areas of the world.

UHLED has more than 500 workers and a strong R&D team with 30 employees.

Also UHLED has the DIP, SMT and other advanced equipments for high efficiency Productions.

UHLED also has a professional QC team. They will double check all the quality details before delivery.

With high quality, good reputation and competitive price, UHLED is going to achieve more in the global market.

Specifications:

Outdoor P8 Advertising LED display(SMD)
Product type	P8
Pixel pitch	8mm
Pixel constitution	1R1G1B
LED package mode	SMD3528/SMD3535
Pixel density	15625dots/㎡
Scan mode	4
Brightness	5000 cd/㎡ / 5500cd/㎡
Module resolution	32*16
Module size	256*128mm
Max. consumption	1000W/㎡
Ave. consumption	400W/㎡
Viewing angle	Horizontal 120°/Vertical 100°
Cabinet	Customized (size, color, design etc.)
Control Method	Synchronous
Frame frequency	≧ 60Hz
Refresh Rate	≧ 400Hz,Max. 2000Hz
Grey level	≧ 4K grade
Brightness adjustment	Manual or Auto 100 grade
Working temperature	-10 OC — +45 OC
Working voltage	AC220V±10%；50Hz(AC110V optional)
Video interface	VGA,DVI,CVBS,Y/C,YPbPr,SDI/HDSDI,HDMI etc
Communication distance	Network cable≦100m; Multimode Fiber≦500m; Single mode Fiber≦10km
Average fault-free	5000hours
Life span
