Water Filling Machine 4Kw Beverage Plastic Bottle Capping Equipment

CGF series water bottled production line Barrel

Quick Detail:

1. Product: CGF series water bottled production line

3. Main Material: SS304/316

4. Production capacity: 6000bph(500ml)

5. Usage: Fill pure/mineral/distilled water and so on

6. Dimension: 2450*1800*2200mm

7. Warranty: 1year free

Water Filling Machine Beverage Plastic Bottle Capping Equipment

Description:

?CGF series water bottled production line

1. Each water filling?machine element than contacts with the liquid is made of high quality Stainless steel 304, if needed, SS 316 is also available.

2. The water filling machine adopts bottle neck holding transmission technology to realize fully automatic rinsing,?filling and capping.

3. Most elements of the electrical system use famous international brand, such as Mitsubish, Omron brand.

4.?The water filling machine obtains the advantages of good abrasive resistance, high stability, low failure rate, etc. The quality of the equipments reaches the international advanced level.

5. Advanced technologies, human-machine interface touch screen and PLC program control are adopted in this?machine.

6. Nozzles in the grab can guarantee the complete wash of the interior of the bottle.

7. Easy to operate, save the cost of workers.

Application:

This machine is designed for bottling non-air drinks, such as pure water, mineral water etc, it
integrates bottle washing, filling and capping into one monobloc unit.

Specifications:

CGF series water bottled production line

1. This equipment is automatic washing filling capping three in one machine. It’s of many advantages, such as compact structure, perfect control system and easy to be operated. Advanced touch screen and PLC control system makes man-machine communication true.

2. Washing part is mainly composed of washing pump, bottle clamps, water distributor, up turn-plate, guide rail, protection cover, spraying device, defrosting tray, rinse water take and rinse water refluxing tank.

3. Filling Part is mainly composed of filling barrel, filling valves (normal temperature and normal pressure filling), filling pump, bottle hanging device / bottle pedestals, elevating device, liquid indicator, pressure gauge, vacuum pump, etc.

4. Capping part is mainly composed of capping heads, cap loader (separated), cap unscrambler, cap drop rail, pressure regular, cylinder and also we need an air compressor as the auxiliary external equipment.

5. Main electrical components are all imported from world famous brands to guarantee excellent performance of the whole machine.

2) Technical parameter
