Product Details
| Brand Name | Zhibosen | Place of Origin | China | |
| Model Number | ZBS900D-12 |
Product Description
Certification:CC,CE,FC,ROSH
Sharp Security Indoor 520 TVL CCTV Mini Camera 12V DC ,? Digital Signal Processing System
?
?
Quick Detail:
?
?
1. Model Number:?ZBS900D-12
2. Brand Name: ZHIBOSEN
3. Type: CCTV Mini camera
4.?Imaging device: 1/3 CMOS
5.?System format: PAL or NTSC
6. View angle:?55 degrees
6. Pixel: 520TVL
7. Place of Origin: Guangdong China
8. Gross Weight: 0.5kg
9. Package Size: 13x8x7cm
?
?
Description:
?
??
It’s?an ultra small? high definition CCTV camera with excellent night vision. Size is 11.5X11.5X21mm only, Weight is 2g! Very easy to install and conceal. Minimum illumination is 0.008lux, which can view clearly in?almost?complete darkness. Full TV system.
Applicable worldwide.
1. 520 TVL mini cctv camera?
2. 0.008lux for excellent night vision.?
3. Ultra small size.?
4. Can be used at FPV.?
5. Both NTSC/PAL.?
2. 0.008lux for excellent night vision.?
3. Ultra small size.?
4. Can be used at FPV.?
5. Both NTSC/PAL.?
Applications:?
Use for Home and Business Security, Shops, Pubs and Restaurants, Building Sites, Warehouses, Boats, Marine Use, Sports use, Wildlife, Farms, Stables and Kennels, Surveillance and Covert use, Nursery and child care, Firearm.?
Specifications :
|
PICK UP ELEMENT
|
Single chip 1/3 CMOS
|
|
|
SYSTEM
|
NTSC
|
PAL
|
|
NUMBER OF PIXEL
|
NTSC:656(H)×492(V)
|
PAL:786(H)×576(V)
|
|
IMAGE SIGNAL PROCESS
|
Digital Signal Processing System
|
|
|
SENSOR DIMENSION
|
4.75mm(H)×3.55mm(V)
|
|
|
HORIZONTAL RESOLUTION
|
Approximately 520TV Lines
|
|
|
SCANNING SYSTEM
|
2:1 Interlace
|
|
|
SENSITIVITY
|
0.008Lux/F1.2
|
|
|
LENS?&?VIEW?ANGLE
|
0.5mm F2.0 /55 °
|
|
|
S/N RATIO
|
52dB
|
|
|
ELECTRONIC SHUTTER
|
OUT (1/60 S TO 1/100000 S)
|
OUT (1/50 S TO 1/100000)S
|
|
AUTO GAIN CONTROL
|
OUT
|
|
|
WHITE BALANCE CONTROL
|
OUT
|
|
|
BACK LIGHT COMPENSATION
|
OUT
|
|
|
VIDEO ?OUT
|
1.0V p-p/75ohm
|
|
|
AUDIO ?OUT
|
1.0V p-p/1Kohm
|
|
|
SIZE ?(L x W x H)
|
11.5mm x 11.5mm x 21mm
|
|
|
WEIGHT
|
2g
|
|
|
WORK CURRENT
|
70mA
|
|
|
POWER REQUIREMENT
|
DC 6V-24V
|
|
|
OPERATING TEMPERATURE
|
- 10° C ~ +50°C ,less than?90% RH
|
|
|
Connection
|
PIN1-Red DC5V ?PIN2-Black GND ?PIN3-Yellow VIDEO OUT?
|
Competitive advantages:?
?
?
good price, reliable quality, guarantee of delivery,good services
