CPU 224 Kitchen Aluminum Foil Rewinding Production Line , Paper Rewinding Machine

CPU 224 Kitchen Aluminum Foil Rewinding Production Line , paper rewinding machine

Kitchen Aluminum Foil Roll Rewinding Machine Production Line for Household Food Fruit Factory Price

Quick Detail:

The fourth generation ideal machine mainly used for cutting soft temper material, such as aluminum foil, Kraft paper and parchment etc.

? ? ? ? ? ? A. ? ? ? ?Complete with CPU 224 Control Panel Board from German Siemens.

? ? ? ? ? ? B. ? ? ? ?With auto feeding aluminum foil speed control, alignment and adjustment

? ? ? ? ? ? C. ? ? ? Fully auto core loading, gluing, slitting and rewinding of foil rolls

D. ? ? ? Complete with meter cutting length control.

E. ? ? ? Combination of both Western & Asian Technologies on complete production and control.

F. ? ? ? Built in position for Embossing Roller, so do not need another embossing machine for embossing foil.

G. ? ? ? High productivity and user-friendly

H. ? ? ? Complete with all safety features

I. ? ? ? Customized build to respective buyer’s requirement

Specification:

Description:

? Kitchen foil cutting and wrapping machinery, main include open-roll, roller, material traction system, auto rotary link foil system, up pipe system, roll-up system, and ultraviolet disinfection system. For its reasonable layout, complete equipment is compact structure and elegant appearance .Every part’s function, structure features and caution of adjustment are as follows:

1). ?Decoiling

?? This part has coupling alignment and horizontal adjustment mechanism, drive each hand-wheel can make the material keep to middle, and the aluminum foil roll parallel to the roller. The stroke of coupling alignment and horizontal adjustment both are ±20mm.

2). Stretch roller

?? Rolling up to the traction roller, need to set a roller running and some stretch motion in the station, in order to eliminate tension pulsation phenomenon and wrinkling phenomenon when the foil roll opened. That can make the foil flat when the foil into the running station.

3) ?Foil material traction system

?? This part is the main power part for the foil transporting, drivered by the variable frequency s
