Purlin Roll Forming Machine Auto 14 Rolling Station Hydraulic Forming Machine

FOB Price

Negotiable / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HRF		Place of Origin	China
Model Number	C80--300

Delivery Time:50-60 days
Certification:CE

C80-300 PURLIN FORMING MACHINE

Descrition:

1: The C Purlin product application is used widely in the field of steel building structure.

2: The C purlin forming machine can produce the width from 80mm to 300mm and height from 50mm to 80mm and steel thickness is from 1.5mm up to 3.0mm

3: It is easy to change the spacers between the rollers and produce another width .

4. With stable operation,low noise and high production performance

5. It just needs half an hour to finish one width to another width

Applications:

C channels, C lipped chanels ,C purlins

Specifications:

Main specification

NO.	Items	Unit	Main specification
1	Material thickness	mm	1.5-3.0
2	Forming speed	m/min	12-15
3	Roll station	/	14 stations(depend on the profile)
4	Main power	kw	15
5	Hydraulic power	kw	7.5
6	Control system
