34mm Titanium Compression Driver Tweeter 8ohm , 1.2KHz - 20KHz

34mm Titanium Compression Driver Tweeter 8ohm , 1.2KHz? - 20KHz

8ohm CY-3442S Compression Driver Tweeter Driver

Description:

1.34mm titanium compression driver
fessional compression driver
3.good quality driver
4.OEM & ODM

Specifications:

Throat Diameter : 1 in (25mm )

Mounting Type : Screw on 1-3/8\'\' - 18TPI or Bolt-on

Nominal Impedance : 8ohm

Power Capacity : 40Watts RMS

Sensitivity( 1W/1M) : 108dB

Frequency Range : 1.2KHz ~ 20KHz

Diaphragm Material? : Titanium

Voice Coil Diameter : 1.35 in ( 34.4mm )

Voice Coil Materail : Round & Ribbon Aluminium Wire

Flux Density : 1.45T

Magnet : Strontium Ferrite

Overall Diameter / Depth : 90mm (3.54in )/ 62.5mm ( 2.46in )

Net weight : 0.97KG

Overview:

High quality compression driver offering excellent efficiency and low distortion. It is recommended for use in studio monitors, stage boxes, and sound reinforcement in small to medium rooms.

Highlights:

Titanium diaphragm for durability and extended HF response

Optimized phase plug eliminate phase cancellation problems

High-temperature voice coil materials ensure reliability

Smooth, extended frequency response

Easy diaphragm replacement
