P10 3-IN-1 SMD 8 Bit Curtain LED Display Panel Full Color , 10000 Pixels/

FOB Price

Negotiable / Unit

1 Unit(Min.Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	TeehoLED		Place of Origin	China
Model Number	CE, 3C , RoHS, ISO,FCC,UL

Product Description

Delivery Time:15-35days
Certification:CE,UL, ROHS, 3C, ISO,FCC

Quick Detail:

1.Special design
2.SMD3528 lamp.
3.With flexible design, it is very easy to install.
4.Module material: ABS plastic and Aluminum.

P10 3-IN-1 SMD 8 Bit Full Color Curtain LED Display , 10000 Pixels/ ㎡

Description:

1),LED video Curtain display with CE , ROHS,FCC.
2),High brightness and support brightness automatically adjustment,Mainly used stage show.
3),Long lifespan, can reach more than 50,000 hours;
4),Easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED curtain display system;
5),Rich LED curtain display engineering experience both in domestic and international market.

Applications:

Airport&Station
Television Relay
Advertising media
Sports stadiums
Public area
Music concert

Specifications:

Part Number	Teeho-P10
Resolution	48 (H)× 96 (V)
Pixel Pitch	10mm
LED Configuration	1R 1 G 1 B 3-IN-1 SMD
Pixel Density	10000 pixels/ ㎡
Size	480× 960 ×50 mm
Depth	<90mm
Weight	9kg
Mechanical Ratings
Hanging Weight Support	2T
Surface Flatness	Gap<0.5mm
Optical Ratings
Brightness	1800 cd/ ㎡
View Angle	150°/150°
Gray Scale	8bits input, correction with 14bits
Display COLOR	16.7M
Transparent Ratio	30%
Brightness Adjustment	0～100% 10 level
Power Supply
Operation Power	90～260V 50～60Hz
Max. Power Consumption	400W/ ㎡
Average Power Consumption	150W/ ㎡
Control System
Control Mode	Synchronous display with control PC by DVI
Frame Update Frequency	60～85Hz
Screen Refresh Frequency	500Hz
Gamma Correction	-5.0～+5.0
Support Input	Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Control Distance	Ethernet cable<120m or Fiber Optic<10Km
Brightness Correction	Pixel, Module, Cabinet
Environmental
Operating Temperature	-20°～+60°
Operating Humidity	10～95% RH
Operating Life	100,000hours
MTBF	5000hours
Protection Level	IP65
Out of Control Rate
