9 Watt 32V - 34V COB LED Array For Track Light , 45mil Bridgelux Chip

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Lepower		Place of Origin	China
Model Number	LY-WH020303B4545

Product Description

Delivery Time:5-10 days
Certification:CE, RoHS, EN62471

1000lm 9W high power led module with Bridgelux 45mil chip for outdoor lighting

Quick Detail:

9W power consumption Integrated package, high light efficiency Brideglux led chip customized 9-11V, 900mA, up to 110lm/W,Ra>70 Size: 20mm*20mm Warm white/Neutral white/Cool white optional Good thermal conductivity design, well heat dissipation to reduce the light decay and extend the lifetime of the light source. Suitable for wide range applications, the variety of working environment. High light efficiency but low power consumption. 2 years warranty

9 Watt COB LED Array For Track Light , 45mil Bridgelux Chip

Description:

With compact structure and convenient for welding operation. Integrated package, 8-15W different power customized Super high lumens light source Several led chips available, easy selection with your goal. Thermal conductivity design, well heat dissipation to reduce the light decay and extend the lifetime of the light source.

Applications:

Flood light High bay light Track light Down light

Specification:

Dimension

Equivalent circuit diagram

Electrical/Optical Characteristics (At TA=25°C)

Parameter	Symbol	Conditions	Min.	Avg.	Max.	Units
Luminous Flux	Φ	IF=900mA	950	--	1050	lm
Color Rendering Index	CRI	IF=900mA	? ?	70	? ?	Ra
Color Temperature/ Color coordinates	CCT	IF=900mA	2800	--	3000	K
Forward Voltage	VF	IF=900mA	9	--	11	V
Luminous efficiency	Φ	IF=900mA	90	--	100	Lm/W
Thermal Resistance Junction To Board?	RΘJ-B	IF=900mA	? ?	2	? ?	°C/W
Reverse Current	IR	VR=17V	? ?	? ?	2	μA
Viewing Angle [1]	2Θ1/2	IF=900mA	? ?	130	? ?	Deg

Absolute Maximum Rating(At TA=25°C)

Parameter	Symbol	Ratings	Units
Power Dissipation	PD	9	W
Continuous Forward Current	IF
